Product Information
This FortiGate 121G bundle comes with 1 year of FortiCare Premium support and 1 year of FortiGuard Enterprise Protection. The 121G is the 120G series 1U model with a 480 GB SSD, rated at 39 Gbps firewall (1518-byte UDP) and 6.7 Gbps application control, with 3 million concurrent sessions and 16,000 client to gateway IPsec tunnels. It has sixteen Gigabit RJ-45 ports, eight SFP ports, four 10G SFP+ FortiLink ports, HA and management ports and Bluetooth LE.
Key Features
- 1 yr Premium + Enterprise Protection
- 480 GB SSD
- 39 Gbps firewall (listed)
- 16 x 1G RJ-45 + 8 x SFP
- 4 x 10G SFP+ FortiLink
- 1U rack mount
Product Information
Brand: Fortinet
Manufacturer: Fortinet
Product Line: Fortinet FortiGate
Model: 121G
Product Type: Security appliance
Packaged Quantity: 1
Network and Communication
Connectivity Technology: Wired
Data Link Protocols: 10 Gigabit Ethernet, Bluetooth LE, Ethernet, Fast Ethernet, Gigabit Ethernet
Network Standard: HTTP, HTTPs, IPSec, IPv6, TCP/IP, UDP/IP
Remote Management: HTTP, HTTPS
Encryption: 256-bit AES, 256-bit SHA, SSL, TLS 1.3
Capacity: Client to gateway IPSec VPN tunnels: 16000, Concurrent sessions: 3000000, Concurrent SSL VPN users: 500, Firewall policies: 10000, Gateway to gateway IPSec VPN Tunnels: 2000, Maximum number of switches: 32, Maximum virtual domains: 10, New sessions per second: 140000, Number of FortiAP devices (tunnel): 64, Number of FortiAP devices: 128, Number of FortiToken devices: 5000, SSL inspection concurrent sessions: 315000, SSL inspection CPS: 2100, Virtual domains: 10
Wireless LAN: Bluetooth LE
Network Device: Application control throughput (HTTP 64K): 6.7 Gbps, CAPWAP Throughput (HTTP 64K): 35 Gbps, Firewall latency (64-byte UDP): 3.17 µs, Firewall throughput (1518-byte UDP): 39 Gbps, Firewall throughput (512-byte UDP): 39 Gbps, Firewall throughput (64-byte UDP): 28 Gbps, Firewall throughput: 42 Mpps, IPS throughput (enterprise traffic mix): 5.3 Gbps, NGFW throughput: 3.1 Gbps, SSL inspection throughput: 3 Gbps, Threat protection throughput: 2.8 Gbps, VPN throughput (512-bit IPSec): 35 Gbps, VPN throughput (SSL): 1.5 Gbps
Operating System Edition: FortiOS
Features: CAPWAP support, High Availability, Reset button, SSL inspection, Trusted Platform Module (TPM), VPN support
Bundled Services: 1 year FortiCare Premium Support + 1 year FortiGuard Enterprise Protection
Connectivity
Interface Provided: 1 x 1000Base-T (HA) - RJ-45, 1 x 1000Base-T (management) - RJ-45, 1 x console - RJ-45, 1 x USB 3.0 - Type A, 16 x 1000Base-T - RJ-45, 4 x 10GBase-X (FortiLink) - SFP+, 8 x 1000Base-X - SFP
Power
Device Type: Internal power supply
Memory and Processor
Processor Brand: Fortinet
Processor Type: FortiASIC SP5
Hard Drive Capacity: 480 GB
Port Expansion Hard Drive Type: SSD
Technical Information
Min Operating Temperature: 32 degree Fahrenheit
Max Operating Temperature: 104 degree Fahrenheit
Operating Humidity: 10 - 90% (non-condensing)
Physical Characteristics
Form Factor: Rack-mountable
Height (Rack Units): 1
Airflow Direction: Side to back airflow
Status Indicators: Alarm, HA, Power, Status
Installed Quantity: 1
Dimensions and Weight
Height: 1.7 inch
Width: 17 inch
Depth: 10 inch
Weight: 12.17 lbs
Included Items
Included Accessories: 2 mounting brackets, 4 rubber feet, 8 screws
Cables: 1 x network cable, 2 x power cable
Warranty
Service Activation: No
