Product Information
This is the TAA compliant FortiGate 200G with 3 years of FortiCare Premium support and 3 years of FortiGuard Enterprise Protection (FG-200G-TAA-FGDUS-BDL-809-36). The 200G is a 1U firewall rated at 39 Gbps firewall (1518-byte UDP), 27.8 Gbps application control and 9 Gbps IPS, with up to 11 million TCP sessions and 400,000 new sessions per second. It has eight 1/2.5/5G and eight Gigabit RJ-45 ports, eight 10G SFP+ ports, four SFP ports, HA and management ports, Bluetooth LE and dual redundant power supplies. The description quotes 3 Gbps firewall and 6 Gbps VPN, which does not match the spec.
Key Features
- TAA compliant
- 3 yr Premium + Enterprise Protection
- 39 Gbps firewall (1518-byte UDP)
- 8 x 2.5/5G + 8 x 1G RJ-45
- 8 x 10G SFP+ + 4 x SFP
- 1U, dual redundant PSU
Product Information
Brand: Fortinet
Manufacturer: Fortinet
Product Line: Fortinet FortiGate
Model: 200G
Product Type: Security appliance
Packaged Quantity: 1
Color Category: White
Network and Communication
Connectivity Technology: Wired
Data Link Protocols: 10 Gigabit Ethernet, 2.5 Gigabit Ethernet, 5 Gigabit Ethernet, Bluetooth LE, Ethernet, Fast Ethernet, Gigabit Ethernet
Network Standard: DNS, HTTP, HTTPs, IPSec, IPv4, IPv6, TCP/IP, UDP
Remote Management: DNS, HTTP, HTTPS, IPv4, IPv6, TCP/IP, UDP
Encryption: 256-bit AES, 256-bit SHA, SSL, TLS 1.3
Capacity: Client to gateway IPSec VPN tunnels: 16000, Concurrent SSL VPN users: 500, Concurrent TCP sessions (enterprise traffic mix): 11000000, Firewall policies: 10000, Gateway to gateway IPSec VPN Tunnels: 2000, Maximum number of FortiTokens: 5000, Maximum virtual domains: 10, New TCP sessions per second: 400000, Number of FortiAP devices (tunnel mode): 128, Number of FortiAP devices: 256, Number of FortiSwitches: 64, SSL inspection concurrent sessions: 900000, SSL inspection CPS: 7100, Virtual domains: 10
Network Device: Application control throughput (HTTP 64K): 27.8 Gbps, CAPWAP Throughput (HTTP 64K): 37.5 Gbps, Firewall latency (64-byte UDP): 4.36 μs, Firewall throughput: 39.75 Mpps, IPS throughput (enterprise traffic mix): 9 Gbps, IPv4 firewall throughput (1518-byte UDP): 39 Gbps, IPv4 firewall throughput (512-byte UDP): 39 Gbps, IPv4 firewall throughput (64-byte UDP): 26.5 Gbps, IPv6 firewall throughput (1518-byte UDP): 39 Gbps, IPv6 firewall throughput (512-byte UDP): 39 Gbps, IPv6 firewall throughput (64-byte UDP): 26.5 Gbps, NGFW throughput (enterprise traffic mix): 7 Gbps, SSL inspection throughput: 7 Gbps, Threat protection throughput (enterprise traffic mix): 6 Gbps, VPN throughput (512-bit IPSec): 36 Gbps, VPN throughput (SSL): 3 Gbps
Operating System Edition: FortiOS
Features: Advanced sandbox detection, AI/ML powered, Anti-malware protection, Built-in ASIC, CAPWAP support, Data Loss Prevention (DLP), DDoS Protection, DNS filtering, Firewall protection, High Availability, Intrusion Prevention System (IPS), NGFW appliance, SD-WAN support, Secure Access Service Edge (SASE), Self-healing network, SSL inspection, Trusted Platform Module (TPM), URL protection, VPN support, Zero Trust Network Access (ZTNA)
Bundled Services: 3 years FortiCare Premium Support + 3 years FortiGuard Enterprise Protection
Connectivity
Interface Provided: 1 x 1 Gigabit Ethernet (High Availability) - RJ-45, 1 x 1000Base-T (management) - RJ-45, 1 x console - RJ-45, 1 x USB 3.0 - Type A, 4 x 1000Base-X - SFP, 8 x 1/2.5/5GBase-T - RJ-45, 8 x 1000Base-T - RJ-45, 8 x 10GBase-X - SFP/SFP+
Power
Device Type: Internal power supply
Required Voltage: AC 100-240 volt
Frequency: 50/60 hertz
Power Consumption Operational: 145 watt
Power Supplies Installed: 2
Power Supplies Supported: 2
Redundant Power Supply: Yes
80 PLUS Certification: 80 PLUS
Memory and Processor
Processor Brand: Fortinet
Processor Type: FortiASIC CP10/NP7Lite
Processors Installed: 1
Technical Information
Min Operating Temperature: 32 degree Fahrenheit
Max Operating Temperature: 104 degree Fahrenheit
Operating Humidity: 5 - 90% (non-condensing)
Physical Characteristics
Form Factor: Rack-mountable
Height (Rack Units): 1
Airflow Direction: Front and side to back
Status Indicators: Alarm, HA, Power, Status
Dimensions and Weight
Height: 1.8 inch
Width: 17 inch
Depth: 15 inch
Weight: 14.11 lbs
Warranty
Service Activation: No
