Product Information
The Fortinet FortiGate 3000G is a 2U data center firewall rated at 90 Gbps IPS, 85 Gbps NGFW and 80 Gbps threat protection, with 38 ports in total: six 40/100G QSFP28 ports, sixteen 1/10/25G SFP28 ports, fourteen 1/10G RJ-45 ports, two 1/2.5/5/10G WAN ports and two 10G management ports. It has dual redundant power supplies and draws about 550 W. This is the hardware without a service bundle.
Key Features
- 85 Gbps NGFW
- 90 Gbps IPS
- 6 x 100G QSFP28
- 16 x 25G SFP28
- 14 x 10G RJ-45 + 2 WAN
- 2U, dual redundant PSU
Product Information
Brand: Fortinet
Manufacturer: Fortinet
Product Line: Fortinet FortiGate
Model: 3000G
Product Type: Security appliance
Packaged Quantity: 1
Color Category: White
Network and Communication
Connectivity Technology: Wired
Data Link Protocols: 10 Gigabit Ethernet, 100 Gigabit Ethernet, 25 Gigabit Ethernet, 40 Gigabit Ethernet, Gigabit Ethernet
Encryption: SSL, TLS 1.3
Network Device: IPS throughput: 90 Gbps, NGFW throughput: 85 Gbps, Threat protection throughput: 80 Gbps
Operating System Edition: FortiOS
Features: DDoS Protection, Intrusion Prevention System (IPS), SSL inspection, Trusted Platform Module (TPM), Virtual Extensible LAN (VXLAN), Zero Trust Network Access (ZTNA), Zero-touch provisioning (ZTP)
Connectivity
Ports: 38
Interface Provided: 1 x console, 1 x USB, 14 x 1Gb Ethernet/10Gb Ethernet - RJ-45, 16 x 1 Gigabit Ethernet/10Gb Ethernet/25Gb Ethernet - SFP/SFP+/SFP28, 2 x 1 Gigabit Ethernet/10Gb Ethernet (management) - RJ-45, 2 x 1/2.5/5/10 Gigabit Ethernet - RJ-45 (WAN), 6 x 40Gb Ethernet/100Gb Ethernet - QSFP+/QSFP28
Power
Device Type: Internal power supply
Required Voltage: AC 100-240 volt
Frequency: 50 - 60 hertz
Power Consumption Operational: 550 watt
Power Supplies Installed: 2
Power Supplies Supported: 2
Redundant Power Supply: Yes
Hot-Plug: Hot-plug
80 PLUS Certification: 80 PLUS Platinum
Memory and Processor
Processor Brand: Fortinet
Processor Type: FortiASIC NP7
Processors Installed: 1
Technical Information
Min Operating Temperature: 32 degree Fahrenheit
Max Operating Temperature: 113 degree Fahrenheit
Operating Humidity: 5 - 90% (non-condensing)
Physical Characteristics
Form Factor: Rack-mountable
Height (Rack Units): 2
Status Indicators: Alarm, HA, Power, Status
Dimensions and Weight
Height: 3.5 inch
Width: 17.2 inch
Depth: 19.5 inch
Weight: 33.73 lbs
Included Items
Included Accessories: 2 x SR 10Gbps SFP+ transceivers
Warranty
Service Activation: No
