Product Information
This FortiGate 31G bundle comes with 5 years of 24x7 FortiCare support and FortiGuard Unified (UTM) Protection. The 31G is the 30G model with 30 GB of storage, a small desktop firewall rated at 4 Gbps firewall (1518-byte UDP), 830 Mbps application control and 800 Mbps IPS, with up to 600,000 TCP sessions, 2,000 policies and 250 client to gateway tunnels. It has one WAN, one FortiLink and two Gigabit LAN ports plus a console. The description lists 200 policies and 2,000 client tunnels, the spec values are used here.
Key Features
- 5 yr 24x7 FortiCare + UTM
- 30 GB local storage
- 4 Gbps firewall (1518-byte UDP)
- 600,000 TCP sessions
- 1 WAN + 1 FortiLink + 2 LAN
- Desktop, cloud managed
Product Information
Brand: Fortinet
Manufacturer: Fortinet
Product Line: Fortinet FortiGate
Model: 31G
Product Type: Security appliance
Packaged Quantity: 1
Color Category: White
Network and Communication
Connectivity Technology: Wired
Data Link Protocols: Ethernet, Fast Ethernet, Gigabit Ethernet
Network Standard: DNS, HTTP, HTTPs, IPSec, IPv4, IPv6, TCP/IP, UDP
Remote Management: DNS, HTTP, HTTPS, IPv4, IPv6, TCP/IP, UDP
Encryption: 256-bit AES, 256-bit SHA, SSL, TLS 1.3
Capacity: Client to gateway IPSec VPN tunnels: 250, Concurrent TCP sessions (enterprise traffic mix): 600000, Firewall policies: 2000, Gateway to gateway IPSec VPN Tunnels: 200, Maximum number of FortiTokens: 500, New TCP sessions per second: 30000, Number of FortiAP devices (tunnel mode): 8, Number of FortiAP devices: 16, Number of FortiSwitches: 8, SSL inspection concurrent sessions: 55000, SSL inspection CPS: 260
Network Device: Application control throughput (HTTP 64K): 830 Mbps, Firewall latency (64-byte UDP): 2.87 µs, Firewall throughput: 5.85 Mpps, IPS throughput (enterprise traffic mix): 800 Mbps, IPv4 firewall throughput (1518-byte UDP): 4 Gbps, IPv4 firewall throughput (512-byte UDP): 4 Gbps, IPv4 firewall throughput (64-byte UDP): 3.9 Gbps, IPv6 firewall throughput (1518-byte UDP): 4 Gbps, IPv6 firewall throughput (512-byte UDP): 4 Gbps, IPv6 firewall throughput (64-byte UDP): 3.9 Gbps, NGFW throughput (enterprise traffic mix): 570 Mbps, SSL inspection throughput: 400 Mbps, Threat protection throughput (enterprise traffic mix): 500 Mbps, VPN throughput (512-bit IPSec): 3.5 Gbps
Operating System Edition: FortiOS
Features: Advanced sandbox detection, AI/ML powered, Anti-malware protection, Built-in ASIC, Data Loss Prevention (DLP), DDoS Protection, DNS filtering, Firewall protection, High Availability, Intrusion Prevention System (IPS), NGFW appliance, Reset button, SD-WAN support, Self-healing network, SSL inspection, Trusted Platform Module (TPM), URL protection, VPN support, Wall mountable, Zero Trust Network Access (ZTNA)
Bundled Services: 5 years 24x7 FortiCare and FortiGuard Unified (UTM) Protection
Connectivity
Ports: 4
Interface Provided: 1 x 1000Base-T - RJ-45 (WAN), 1 x 1000Base-T (FortiLink) - RJ-45, 1 x console - RJ-45, 2 x 1000Base-T - RJ-45
Power
Device Type: External power adapter
Memory and Processor
Processor Brand: Fortinet
Processor Type: FortiASIC SOC4
Hard Drive Capacity: 30 GB
Technical Information
Min Operating Temperature: 32 degree Fahrenheit
Max Operating Temperature: 104 degree Fahrenheit
Operating Humidity: 20 - 90% (non-condensing)
Physical Characteristics
Form Factor: Desktop
Status Indicators: HA, Power, Status
Installed Quantity: 1
Dimensions and Weight
Height: 1.6 inch
Width: 5.6 inch
Depth: 6.3 inch
Weight: 21.16 ounce
Warranty
Service Activation: No
Not sure this is the right security appliance for your site? Send us your user count, internet speed and current firewall model and the DatorPro team will help you confirm the fit before you order.
