Product Information
The Fortinet FortiGate 3801G is a 3U hyperscale data center firewall with a 1.92 TB drive, rated at 795 Gbps firewall (1518-byte UDP), 315 Gbps application control, 250 Gbps IPS, 210 Gbps NGFW and 200 Gbps threat protection, with up to 200 million TCP sessions and 1.1 million new sessions per second. It has four 400G QSFP-DD ports, six 200G QSFP56 ports, eighteen 50G SFP56 ports, two 10G management ports and four redundant power supplies.
Key Features
- 795 Gbps firewall (1518-byte UDP)
- 210 Gbps NGFW
- 200M TCP sessions
- 4 x 400G QSFP-DD
- 6 x 200G + 18 x 50G
- 3U, 4 redundant PSUs
Product Information
Brand: Fortinet
Manufacturer: Fortinet
Product Line: Fortinet FortiGate
Model: 3801G
Product Type: Security appliance
Packaged Quantity: 1
Color Category: White
Network and Communication
Connectivity Technology: Wired
Data Link Protocols: 10 Gigabit Ethernet, 200 Gigabit Ethernet, 400 Gigabit Ethernet, 50 Gigabit Ethernet, Gigabit Ethernet
Network Standard: IPSec, TCP/IP, UDP/IP
Remote Management: HTTP, HTTPS
Encryption: 256-bit AES, 256-bit SHA, SSL, TLS 1.3
Capacity: Client to gateway IPSec VPN tunnels: 200000, Concurrent SSL VPN users: 30000, Concurrent TCP sessions: 200000000, Firewall policies: 400000, Gateway to gateway IPSec VPN Tunnels: 400000, Maximum number of FortiSwitch: 300, Maximum number of FortiTokens: 20000, Maximum virtual domains: 500, New sessions per second: 1100000, Number of FortiAP devices (tunnel): 4096, Number of FortiAP devices: 8192, Virtual domains: 10
Network Device: Application control (AVC) throughput: 315 Gbps, Firewall latency (64-byte UDP): 3.53µs, Firewall throughput (1518-byte UDP): 795 Gbps, Firewall throughput (512-byte UDP): 793 Gbps, Firewall throughput (64-byte UDP): 453 Gbps, IPS throughput (enterprise traffic mix): 250 Gbps, NGFW throughput (enterprise traffic mix): 210 Gbps, SSL inspection throughput: 120 Gbps, Threat protection throughput (enterprise traffic mix): 200 Gbps, VPN throughput (SSL): 27 Gbps
Features: Anti-malware protection, Firewall protection, SaaS protection, Signed firmware, Trusted Platform Module (TPM), Web threat protection, Zero-day malware detection
Connectivity
Interface Provided: 1 x console, 1 x USB, 18 x 50Gb Ethernet - SFP56, 2 x 10Gb Ethernet (management) - RJ-45, 4 x 400Gb Ethernet - QSFP-DD, 6 x 200Gb Ethernet - QSFP56
Power
Device Type: Internal power supply
Required Voltage: AC 200-240 volt
Frequency: 50/60 hertz
Power Consumption Operational: 1496 watt
Power Supplies Installed: 4
Redundant Power Supply: Yes
Hot-Plug: Hot-plug
Memory and Processor
Processor Brand: Fortinet
Processor Type: FortiASIC CP10/NP7
Hard Drive Capacity: 1.92 TB
Port Expansion Hard Drive Type: SSD
Technical Information
Min Operating Temperature: 32 degree Fahrenheit
Max Operating Temperature: 104 degree Fahrenheit
Operating Humidity: 20 - 90% (non-condensing)
Physical Characteristics
Form Factor: Rack-mountable
Height (Rack Units): 3
Airflow Direction: Front to back airflow
Status Indicators: Alarm, HA, Power, Status
Built-in Devices: 3 x fans, LCD Customer Display
Installed Quantity: 2
Dimensions and Weight
Height: 5.2 inch
Width: 17.2 inch
Depth: 26.1 inch
Weight: 71.65 lbs
Included Items
Included Accessories: 2 x SR 10Gbps SFP+ transceivers, 6 rubber feet
Cables: 1 x console cable, 1 x network cable
Warranty
Service Activation: No
