Product Information
This FortiGate 50G-5G listing is the bundle with 3 years of FortiCare Premium support and 3 years of FortiGuard Enterprise Protection, per the title and part number. The 50G-5G is a desktop firewall with a built in 3G/4G/5G modem, rated at 5 Gbps firewall (1518-byte UDP), 2.25 Gbps IPS and 1.25 Gbps NGFW, with up to 720,000 TCP sessions and 250 client to gateway tunnels. It has one WAN, one FortiLink and three LAN Gigabit ports and Bluetooth LE. The spec lists no bundled service and the description mixes up several figures.
Key Features
- 3 yr Premium + Enterprise Protection
- Built in 5G modem
- 5 Gbps firewall (1518-byte UDP)
- 720,000 TCP sessions
- 1 WAN + 1 FortiLink + 3 LAN
- Desktop, Bluetooth LE
Product Information
Brand: Fortinet
Manufacturer: Fortinet
Product Line: Fortinet FortiGate
Model: 50G-5G
Product Type: Security appliance
Packaged Quantity: 1
Network and Communication
Connectivity Technology: Wired, Wireless
Data Link Protocols: Bluetooth LE, Ethernet, Fast Ethernet, Gigabit Ethernet
Network Standard: DNS, HTTP, HTTPs, IPSec, IPv6, TCP/IP, UDP/IP
Remote Management: HTTP, HTTPS
Encryption: 256-bit AES, 256-bit SHA, SSL, TLS 1.3
Capacity: Client to gateway IPSec VPN tunnels: 250, Concurrent TCP sessions: 720000, Firewall policies: 2000, Gateway to gateway IPSec VPN Tunnels: 200, Maximum virtual domains: 5, New TCP sessions per second: 85000, Number of FortiAP devices (tunnel mode): 8, Number of FortiAP devices: 16, Number of FortiSwitches: 8, Number of FortiToken devices: 500, SSL inspection concurrent sessions: 74000, SSL inspection CPS: 699, Virtual domains: 5
Wireless LAN: Bluetooth LE
Cellular Data Connectivity Technology: HSPA+, LTE, UMTS, WCDMA
Mobile Broadband Access: Yes
Cellular Band: 5G n1/n2/n3/n5/n7/n8/n12/n13/n14/n18/n20/n25/n26/n28/n29/n30/n38/n40/n41/n48/n66/n71/n75/n76/n77/n78/n79 / LTE B1/B2/B3/B4/B5/B7/B8/B12/B13/B14/B17/B18/B19/B20/B25/B26/B28/B29/B30/B32/B34/B38/B39/B40/B41/B42/B43/B46/B48/B66/B71 / HSPA+ B1/B2/B4/B5/B6/B8/B
Network Device: Application control throughput (HTTP 64K): 2.8 Gbps, CAPWAP throughput: 3.8 Gbps, Firewall latency (64-byte UDP): 2.42 µs, Firewall throughput (1518-byte UDP): 5 Gbps, Firewall throughput (512-byte UDP): 5 Gbps, Firewall throughput (64-byte UDP): 4 Gbps, Firewall throughput: 6 Mpps, IPS throughput (enterprise traffic mix): 2.25 Gbps, NGFW throughput (enterprise traffic mix): 1.25 Gbps, SSL inspection throughput: 1.3 Gbps, Threat protection throughput (enterprise traffic mix): 1.1 Gbps, VPN throughput (512-bit IPSec): 4.5 Gbps
IoT Communications Technology: Bluetooth Low Energy (LE)
Internet of Things (IoT) Compatible: Yes
Antennas: 5
Antenna Form Factor: External detachable
Operating System Edition: FortiOS
Features: AI powered, Built-in ASIC, Data Loss Prevention (DLP), DDoS Protection, Firewall protection, GNSS Bias, High Availability, Intrusion Prevention System (IPS), MIMO technology, NGFW appliance, SD-WAN support, Self-healing network, SSL inspection, Trusted Platform Module (TPM), URL filtering, VPN support, Wi-Fi Diversity, WWAN support, Zero Trust Network Access (ZTNA)
Connectivity
Ports: 5
Interface Provided: 1 x 1000Base-T - RJ-45 (WAN), 1 x 1000Base-T (FortiLink) - RJ-45, 1 x console - RJ-45, 1 x USB 3.0 - Type A, 3 x 1000Base-T - RJ-45, 5 x antenna - SMA
Expansion Slots: 2 (total) / 2 (free) x Nano SIM card
Power
Device Type: External power adapter
Required Voltage: AC 100-240 volt
Frequency: 50/60 hertz
Power Consumption Operational: 8.3 watt
Memory and Processor
Processor Brand: Fortinet
Processor Type: FortiASIC SP5
Processors Installed: 1
Technical Information
Min Operating Temperature: 32 degree Fahrenheit
Max Operating Temperature: 104 degree Fahrenheit
Operating Humidity: 10 - 90% (non-condensing)
Physical Characteristics
Form Factor: Desktop
Status Indicators: 5G, Bluetooth Low Energy (BLE), Firmware, HA, Link/activity/speed, Power, Reset, Service, Status, WAN
Dimensions and Weight
Height: 1.6 inch
Width: 8.5 inch
Depth: 6.3 inch
Weight: 2.2 lbs
Warranty
Service Activation: No
Not sure this is the right security appliance for your site? Send us your user count, internet speed and current firewall model and the DatorPro team will help you confirm the fit before you order.
