Product Information
This TAA compliant FortiGate 61F bundle comes with 1 year of FortiCare 24x7 Comprehensive Support and 1 year of FortiGuard protection. The 61F is a desktop firewall with 128 GB of onboard storage, rated at 10 Gbps firewall, 1.8 Gbps application control, 1.4 Gbps IPS, 1 Gbps NGFW, 700 Mbps threat protection and 6.5 Gbps IPsec VPN, with up to 700,000 concurrent TCP sessions and 35,000 new sessions per second. It has two Gigabit RJ-45 WAN ports, a DMZ port, seven internal Gigabit RJ-45 ports, an RJ-45 console and USB 3.0, drawing about 18.7 W.
Key Features
- TAA compliant
- 1 yr 24x7 FortiCare + FortiGuard
- 10 Gbps firewall
- 1 Gbps NGFW
- 128 GB onboard storage
- Desktop, 10 x 1G RJ-45
Product Information
Brand: Fortinet
Manufacturer: Fortinet Federal
Product Line: Fortinet FortiGate
Model: 61F
Product Type: Security appliance
Packaged Quantity: 1
Color Category: White
Country: United States
Network and Communication
Connectivity Technology: Wired
Data Link Protocols: Ethernet, Fast Ethernet, Gigabit Ethernet
Network Standard: HTTPs, IPSec
Remote Management: HTTPS
Encryption: 256-bit AES, 256-bit SHA, SSL
Capacity: Client to gateway IPSec VPN tunnels: 500, Concurrent SSL VPN users: 200, Concurrent TCP sessions: 700000, Firewall policies: 5000, Gateway to gateway IPSec VPN Tunnels: 200, New TCP sessions per second: 35000, Number of FortiAP devices: 30, Number of FortiSwitches: 16, Number of FortiToken devices: 500, Number of registered FortiClients: 200, SSL inspection concurrent sessions: 55000, Virtual domains: 10
Network Device: Application control (AVC) throughput: 1.8 Gbps, CAPWAP throughput: 15 Gbps, Firewall latency (64-byte UDP): 4 µs, Firewall throughput (1518-byte UDP): 10 Gbps, Firewall throughput (512-byte UDP): 10 Gbps, Firewall throughput (64-byte UDP): 6 Gbps, Firewall throughput: 10 Gbps, IPS throughput: 1.4 Gbps, NGFW throughput: 1 Gbps, SSL inspection throughput: 750 Mbps, Threat protection throughput: 700 Mbps, VPN throughput (512-bit IPSec): 6.5 Gbps, VPN throughput (SSL): 900 Mbps
Features: 3G/4G USB Dongle Support, Fanless, FortiLink Mode, SD-WAN support
Bundled Services: 1 year FortiCare 24X7 Comprehensive Support + 1 year FortiGuard
Connectivity
Interface Provided: 1 x 1000Base-T - RJ-45 (DMZ), 1 x console - RJ-45, 1 x USB 3.0 - Type A, 2 x 1000Base-T - RJ-45 (WAN), 7 x 1000Base-T - RJ-45
Power
Device Type: External power adapter
Frequency: 50/60 hertz
Power Consumption Operational: 18.7 watt
Memory and Processor
Hard Drive Capacity: 128 GB
Port Expansion Hard Drive Type: SSD
Technical Information
Min Operating Temperature: 32 degree Fahrenheit
Max Operating Temperature: 104 degree Fahrenheit
Operating Humidity: 10 - 90% (non-condensing)
Physical Characteristics
Form Factor: Desktop
Installed Quantity: 1
Dimensions and Weight
Height: 1.5 inch
Width: 8.5 inch
Depth: 6.3 inch
Weight: 31.74 ounce
Certifications and Listing
Compliant Standards: C-Tick, CB, cUL, FCC Part 15 Class B, ICSA Antivirus, ICSA Firewall certified, ICSA IPSec certified, ICSA SSL-VPN, UL
ENERGY STAR Certified: No
EPEAT Compliant: No
TCO Certified: No
TAA Compliant: Yes
Warranty
Service Activation: No
Not sure this is the right security appliance for your site? Send us your user count, internet speed and current firewall model and the DatorPro team will help you confirm the fit before you order.
