Product Information
The Fortinet FortiGate 700G is a 1U firewall rated at 164 Gbps firewall (1518-byte UDP), 50 Gbps application control, 38 Gbps IPS and 29 Gbps NGFW, with up to 16 million TCP sessions and 700,000 new sessions per second. It has eight 5G RJ-45 ports, sixteen Gigabit SFP ports, four SFP+ ports, four SFP28 ports, a 2.5G HA port and dual redundant power supplies. This is the hardware without a service bundle. The description quotes 14 Gbps firewall, which does not match the spec, please confirm.
Key Features
- 164 Gbps firewall (spec)
- 38 Gbps IPS, 29 Gbps NGFW
- 16M TCP sessions
- 8 x 5G RJ-45 + 16 x SFP
- 4 x SFP+ + 4 x SFP28
- 1U, dual redundant PSU
Product Information
Brand: Fortinet
Manufacturer: Fortinet
Product Line: Fortinet FortiGate
Model: 700G
Product Type: Security appliance
Packaged Quantity: 1
Color Category: White
Network and Communication
Connectivity Technology: Wired
Data Link Protocols: 10 Gigabit Ethernet, 2.5 Gigabit Ethernet, 25 Gigabit Ethernet, 5 Gigabit Ethernet, Ethernet, Fast Ethernet, Gigabit Ethernet
Network Standard: HTTP, HTTPs, IPSec, IPv4, IPv6, TCP/IP, UDP/IP
Remote Management: HTTP, HTTPS
Encryption: 256-bit AES, 256-bit SHA, SSL, TLS 1.3
Capacity: Client to gateway IPSec VPN tunnels: 50000, Concurrent SSL VPN users: 10000, Concurrent TCP sessions: 16000000, Firewall policies: 10000, Gateway to gateway IPSec VPN Tunnels: 2000, Maximum virtual domains: 50, New TCP sessions per second: 700000, Number of FortiAP devices (tunnel): 512, Number of FortiAP devices: 1024, Number of FortiSwitches: 96, Number of FortiToken devices: 5000, SSL inspection concurrent sessions: 1600000, SSL inspection CPS: 13000, Virtual domains: 10
Network Device: Application control throughput: 50 Gbps, CAPWAP throughput: 133 Gbps, Firewall latency (64-byte UDP): 3.87 μs, Firewall throughput: 217.5 Mpps, IPS throughput: 38 Gbps, IPv4 firewall throughput (1518-byte UDP): 164 Gbps, IPv4 firewall throughput (512-byte UDP): 163 Gbps, IPv4 firewall throughput (64-byte UDP): 145 Gbps, IPv6 firewall throughput (1518-byte UDP): 164 Gbps, IPv6 firewall throughput (512-byte UDP): 163 Gbps, IPv6 firewall throughput (86-byte UDP): 145 Gbps, NGFW throughput: 29 Gbps, SSL inspection throughput: 14 Gbps, Threat protection throughput: 26 Gbps, VPN throughput (512-bit IPSec): 55 Gbps, VPN throughput (SSL): 8 Gbps
Operating System Edition: FortiOS
Features: 4 fans, CAPWAP support, High Availability, Trusted Platform Module (TPM), VPN support, Zero Trust Network Access (ZTNA)
Connectivity
Interface Provided: 1 x 1/2.5 Gigabit Ethernet (High Availability) - RJ-45, 1 x 1000Base-T (management) - RJ-45, 1 x console - RJ-45, 16 x 10/100/1000Base-T - SFP, 2 x USB 3.0 - Type A, 4 x 1 Gigabit Ethernet/10Gb Ethernet/25Gb Ethernet - SFP28, 4 x 1000Base-X/10GBase-X - SFP+, 8 x 5GBase-T - RJ-45
Power
Device Type: Internal power supply
Required Voltage: AC 100-240 volt
Frequency: 50/60 hertz
Power Consumption Operational: 230 watt
Power Supplies Installed: 2
Power Supplies Supported: 2
Redundant Power Supply: Yes
Memory and Processor
Processor Brand: Fortinet
Processor Type: FortiASIC CP10/NP7
Technical Information
Min Operating Temperature: 32 degree Fahrenheit
Max Operating Temperature: 113 degree Fahrenheit
Operating Humidity: 10 - 90% (non-condensing)
Physical Characteristics
Form Factor: Rack-mountable
Height (Rack Units): 1
Airflow Direction: Front and side to back
Status Indicators: Alarm, HA, Power, Status
Built-in Devices: 4 x fans
Dimensions and Weight
Height: 1.7 inch
Width: 17 inch
Depth: 13.5 inch
Weight: 7.72 lbs
Included Items
Included Accessories: 2 SX SFP transceivers
Warranty
Service Activation: No
