Product Information
This FortiGate 71G-POE bundle comes with 3 years of FortiCare Premium support and 3 years of FortiGuard Enterprise Protection. The 71G-POE is the 70G-POE model with 64 GB of storage and four PoE+ ports, rated at 10 Gbps firewall (1518-byte UDP), 2.5 Gbps IPS, 1.5 Gbps NGFW and 7.1 Gbps IPsec VPN, with up to 1.4 million TCP sessions. The description lists 200 policies and 5,000 sessions, the spec values are used here.
Key Features
- 3 yr Premium + Enterprise Protection
- 64 GB local storage
- 4 x PoE+ ports
- 10 Gbps firewall (1518-byte UDP)
- 1.4M TCP sessions
- Desktop, cloud managed
Product Information
Brand: Fortinet
Manufacturer: Fortinet
Product Line: Fortinet FortiGate
Model: 71G-POE
Product Type: Security appliance
Packaged Quantity: 1
Color Category: White
Network and Communication
Connectivity Technology: Wired
Data Link Protocols: Ethernet, Fast Ethernet, Gigabit Ethernet
Network Standard: DNS, HTTP, HTTPs, IPSec, IPv6, TCP/IP, UDP/IP
Remote Management: HTTP, HTTPS
Encryption: 256-bit AES, 256-bit SHA, SSL, TLS 1.3
Capacity: Client to gateway IPSec VPN tunnels: 500, Concurrent TCP sessions: 1400000, Firewall policies: 5000, Gateway to gateway IPSec VPN Tunnels: 200, Maximum number of FortiTokens: 500, Maximum virtual domains: 10, New TCP sessions per second: 100000, Number of FortiAP devices (tunnel): 48, Number of FortiAP devices: 96, Number of FortiSwitches: 24, SSL inspection concurrent sessions: 140000, SSL inspection CPS: 715, Virtual domains: 10
Network Device: Application control (HTTP 64K): 3.6 Gbps, CAPWAP Throughput (HTTP 64K): 6.8 Gbps, Firewall latency (64-byte UDP): 2.46 µs, Firewall throughput (1518-byte UDP): 10 Gbps, Firewall throughput (512-byte UDP): 10 Gbps, Firewall throughput (64-byte UDP): 10 Gbps, Firewall throughput: 15 Mpps, IPS throughput: 2.5 Gbps, NGFW throughput: 1.5 Gbps, SSL inspection throughput: 1.4 Gbps, Threat protection throughput: 1.3 Gbps, VPN throughput (512-bit IPSec): 7.1 Gbps
Operating System Edition: FortiOS
Features: 60 W total power budget, AI powered, Bluetooth Low Energy (BLE), Built-in ASIC, CAPWAP support, Data Loss Prevention (DLP), DDoS Protection, Fanless, Firewall protection, High Availability, Intrusion Prevention System (IPS), NGFW appliance, SD-WAN support, Self-healing network, SSL inspection, Trusted Platform Module (TPM), URL filtering, VPN support, Zero Trust Network Access (ZTNA)
Bundled Services: 3 years FortiCare Premium Support + 3 years FortiGuard Enterprise Protection
Connectivity
Ports: 10
Interface Provided: 1 x console - RJ-45, 1 x USB - Type A, 2 x 1000Base-T (FortiLink) - RJ-45, 2 x 1000Base-T (HA) - RJ-45, 2 x 1000Base-T (HA) - RJ-45 (WAN), 4 x 1000Base-T (PoE+) - RJ-45
Power Over Ethernet (PoE): PoE+
Power
Device Type: External power adapter
Memory and Processor
Processor Brand: Fortinet
Processor Type: FortiASIC SP5
Hard Drive Capacity: 64 GB
Port Expansion Hard Drive Type: SSD
Technical Information
Min Operating Temperature: 32 degree Fahrenheit
Max Operating Temperature: 104 degree Fahrenheit
Operating Humidity: 10 - 90% (non-condensing)
Physical Characteristics
Form Factor: Desktop
Status Indicators: Bluetooth Low Energy (BLE), Firmware, Link/activity, PoE max, Power, Reset, Speed, WAN
Installed Quantity: 1
Dimensions and Weight
Height: 1.6 inch
Width: 8.5 inch
Depth: 6.3 inch
Weight: 32.91 ounce
Warranty
Service Activation: No
Not sure this is the right security appliance for your site? Send us your user count, internet speed and current firewall model and the DatorPro team will help you confirm the fit before you order.
