Product Information
This FortiGate 900G bundle comes with 3 years of FortiCare Premium support and 3 years of FortiGuard Unified Threat Protection (UTP). The 900G is a 1U firewall rated at 164 Gbps firewall (1518-byte UDP), 26 Gbps IPS, 22 Gbps NGFW, 20 Gbps threat protection and 55 Gbps IPsec VPN, with up to 16 million concurrent TCP sessions and 720,000 new sessions per second. It has four ultra low latency 1/10/25G SFP28 ports, four 1/10G SFP+ ports, eight SFP ports, sixteen Gigabit RJ-45 ports, an HA port and a management port, with two power supplies.
Key Features
- 3 yr Premium + UTP
- 164 Gbps firewall (1518-byte UDP)
- 22 Gbps NGFW
- 16M concurrent sessions
- 4 x SFP28 ULL + 4 x SFP+
- 1U, dual power supplies
Product Information
Brand: Fortinet
Manufacturer: Fortinet
Product Line: Fortinet FortiGate
Model: 900G
Product Type: Security appliance
Packaged Quantity: 1
Color Category: White
Network and Communication
Connectivity Technology: Wired
Data Link Protocols: 10 Gigabit Ethernet, 2.5 Gigabit Ethernet, 25 Gigabit Ethernet, Gigabit Ethernet
Network Standard: HTTP, HTTPs, IPSec, IPv4, IPv6, TCP/IP, UDP/IP
Remote Management: HTTP, HTTPS
Encryption: 256-bit AES, 256-bit SHA, SSL, TLS 1.3
Capacity: Client to gateway IPSec VPN tunnels: 50000, Concurrent SSL VPN users: 10000, Concurrent TCP sessions: 16000000, Firewall policies: 10000, Gateway to gateway IPSec VPN Tunnels: 2000, Maximum number of FortiTokens: 5000, Maximum virtual domains: 10, New TCP sessions per second: 720000, Number of FortiAP devices (tunnel): 512, Number of FortiAP devices: 1024, Number of FortiSwitches: 96, SSL inspection concurrent sessions: 1600000, SSL inspection CPS: 18000, Virtual domains: 10
Network Device: Application control (HTTP 64K): 74.8 Gbps, CAPWAP Throughput (HTTP 64K): 70 Gbps, Firewall latency (64-byte UDP, ULL ports): 2.5 µs, Firewall latency (64-byte UDP): 3.78 µs, Firewall throughput: 229.5 Mpps, IPS throughput (enterprise traffic mix): 26 Gbps, IPv4 firewall throughput (1518-byte UDP): 164 Gbps, IPv4 firewall throughput (512-byte UDP): 163 Gbps, IPv4 firewall throughput (64-byte UDP): 153 Gbps, IPv6 firewall throughput (1518-byte UDP): 164 Gbps, IPv6 firewall throughput (512-byte UDP): 163 Gbps, IPv6 firewall throughput (86-byte UDP): 153 Gbps, NGFW throughput (enterprise traffic mix): 22 Gbps, SSL inspection throughput: 16.7 Gbps, Threat protection throughput (enterprise traffic mix): 20 Gbps, VPN throughput (512-bit IPSec): 55 Gbps, VPN throughput (SSL): 10 Gbps
Features: AI powered, CAPWAP support, High Availability, Machine learning, SD-WAN support, Trusted Platform Module (TPM), VPN support, Zero Trust Network Access (ZTNA)
Bundled Services: 3 years FortiCare Premium Support + 3 years FortiGuard Unified Threat Protection (UTP)
Connectivity
Interface Provided: 1 x 1/2.5 Gigabit Ethernet (High Availability) - RJ-45, 1 x 1000Base-T (management) - RJ-45, 1 x console - RJ-45, 16 x 1000Base-T - RJ-45, 2 x USB - Type A, 4 x 1 Gigabit Ethernet/10Gb Ethernet - SFP/SFP+, 4 x 1 Gigabit Ethernet/10Gb Ethernet/25Gb Ethernet (ultra-low latency) - SFP/SFP+/SFP28, 8 x 1000Base-X - SFP
Power
Device Type: Internal power supply
Required Voltage: AC 100-240 volt
Frequency: 50/60 hertz
Power Consumption Operational: 134 watt
Power Supplies Installed: 2
Power Supplies Supported: 2
Redundant Power Supply: Yes
Hot-Plug: Hot-plug
80 PLUS Certification: 80 PLUS
Memory and Processor
Processor Brand: Fortinet
Processor Type: FortiASIC CP9/NP7
Technical Information
Min Operating Temperature: 32 degree Fahrenheit
Max Operating Temperature: 113 degree Fahrenheit
Operating Humidity: 10 - 90% (non-condensing)
Physical Characteristics
Form Factor: Rack-mountable
Height (Rack Units): 1
Airflow Direction: Front and side to back
Status Indicators: Alarm, HA, Power, Status
Dimensions and Weight
Height: 1.7 inch
Width: 17 inch
Depth: 15 inch
Weight: 15.98 lbs
Included Items
Included Accessories: 2 SX SFP transceivers
Warranty
Service Activation: No
Not sure this is the right security appliance for your site? Send us your user count, internet speed and current firewall model and the DatorPro team will help you confirm the fit before you order.
