Product Information
This FortiGate Rugged 60F bundle comes with 3 years of 24x7 FortiCare support and 3 years of FortiGuard Unified Threat Protection (UTP). Built for industrial and control environments, the Rugged 60F mounts on a desk, wall or DIN rail and runs on DC power. Listed figures are 6 Gbps firewall (1518-byte UDP), 1.3 Gbps application control, 950 Mbps IPS, 550 Mbps NGFW and 3.5 Gbps IPsec VPN, supporting up to 600,000 TCP sessions and 19,000 new sessions per second. Ports include two RJ-45/SFP combo WAN, four Gigabit RJ-45, an RJ-45 console, a DB-9 serial port and USB 3.0.
Key Features
- 3 yr 24x7 FortiCare + UTP
- Industrial hardened design
- 550 Mbps NGFW
- 600K TCP sessions
- DB-9 serial port
- DC power, DIN rail mount
Product Information
Brand: Fortinet
Manufacturer: Fortinet
Product Line: Fortinet FortiGate Rugged
Model: 60F
Product Type: Security appliance
Packaged Quantity: 1
Color Category: White
Network and Communication
Connectivity Technology: Wired
Data Link Protocols: Ethernet, Fast Ethernet, Gigabit Ethernet
Network Standard: HTTPs, IPSec
Remote Management: HTTPS, MQTT
Encryption: 256-bit AES, 256-bit SHA, SSL, TLS 1.3
Capacity: Client to gateway IPSec VPN tunnels: 500, Concurrent SSL VPN users: 100, Concurrent TCP sessions: 600000, Firewall policies: 5000, Gateway to gateway IPSec VPN Tunnels: 200, New TCP sessions per second: 19000, Number of FortiAP devices (tunnel): 10, Number of FortiAP devices: 30, Number of FortiSwitches: 16, Number of FortiToken devices: 500, SSL inspection concurrent sessions: 70000, SSL inspection CPS: 300, Virtual domains: 10
Network Device: Application control throughput: 1.3 Gbps, Firewall latency (64-byte UDP): 3.1 µs, Firewall throughput (1518-byte UDP): 6 Gbps, Firewall throughput (512-byte UDP): 6 Gbps, Firewall throughput (64-byte UDP): 5.95 Gbps, Firewall throughput: 8.9 Mpps, IPS throughput: 950 Mbps, NGFW throughput: 550 Mbps, SSL inspection throughput: 460 Mbps, Threat protection throughput: 500 Mbps, VPN throughput (512-bit IPSec): 3.5 Gbps, VPN throughput (SSL): 400 Mbps
Operating System Edition: FortiOS
Features: CIP support, CoAP support, Fanless, SD-WAN support
Bundled Services: 3 years 24x7 FortiCare Support + 3 years FortiGuard Unified Threat Protection (UTP)
Connectivity
Interface Provided: 1 x console - RJ-45, 1 x serial - DB-9, 1 x USB 3.0 - Type A, 2 x 1000Base-T/1000Base-X - RJ-45/SFP (mini-GBIC) (WAN), 4 x 1000Base-T - RJ-45
Power
Device Type: External power adapter
Power Consumption Operational: 21 watt
Memory and Processor
Processor Brand: Fortinet
Processor Type: FortiASIC SOC4
Processors Installed: 1
Technical Information
Min Operating Temperature: -40 degree Fahrenheit
Max Operating Temperature: 167 degree Fahrenheit
Operating Humidity: 20 - 90% (non-condensing)
Physical Characteristics
Form Factor: Desktop / wall / DIN rail mountable
Status Indicators: Status
Dimensions and Weight
Height: 1.7 inch
Width: 8.5 inch
Depth: 6.5 inch
Weight: 3.86 lbs
Warranty
Service Activation: No
Not sure this is the right security appliance for your site? Send us your user count, internet speed and current firewall model and the DatorPro team will help you confirm the fit before you order.
