Product Information
Fortinet's FortiNAC M-550F is a 1U network access control manager appliance, not a firewall, that oversees up to 50 FortiNAC devices with LDAP and RADIUS authentication. It has four 10G SFP+ ports, a Gigabit RJ-45 port, a console, 32 GB of RAM, 960 GB of storage and redundant power.
Key Features
- Network access control manager
- Up to 50 managed devices
- 4 x 10G SFP+
- 32 GB RAM
- 960 GB storage
- 1U, redundant power
Product Information
Brand: Fortinet
Manufacturer: Fortinet
Product Line: Fortinet FortiNAC
Model: M-550F
Product Type: Network management device
Packaged Quantity: 1
Network and Communication
Connectivity Technology: Wired
Data Link Protocols: 10 Gigabit Ethernet, Gigabit Ethernet
Remote Management: CLI, DHCP, RADIUS, SNMP, Syslog
Authentication Method: LDAP, RADIUS
Capacity: Managed devices: up to 50
Operating System Edition: FortiNAC-OS F7.2.3 or later
Features: High Availability
Connectivity
Ports: 5
Interface Provided: 1 x 1000Base-T - RJ-45, 1 x console - RJ-45, 4 x 10GBase-X - SFP+
Power
Device Type: Internal power supply
Required Voltage: AC 100-240 volt
Redundant Power Supply: Yes
Hot-Plug: Hot-plug
Memory and Processor
RAID Levels: RAID 1
Processor Brand: AMD
Processor Type: EPYC
Processor Number: 7413
Processors Installed: 1
Clock Speed: 2.65 GHZ
RAM Installed: 32 GB
Memory Technology: DDR4 SDRAM
Hard Drive Capacity: 960 GB
Port Expansion Hard Drive Type: SSD
Technical Information
Min Operating Temperature: 32 degree Fahrenheit
Max Operating Temperature: 104 degree Fahrenheit
Operating Humidity: 5 - 90% (non-condensing)
Physical Characteristics
Form Factor: Rack-mountable
Height (Rack Units): 1
Built-in Devices: 5 x fans
Installed Quantity: 2
Dimensions and Weight
Height: 1.7 inch
Width: 17.2 inch
Depth: 24 inch
Weight: 41.01 lbs
Warranty
Service Activation: No
