Product Information
Fortinet's FortiSwitch 224D-FPOE is a managed switch with 24 Gigabit PoE+ ports and four Gigabit SFP ports. It shares a 370 W PoE budget, offers 56 Gbps of switching throughput and integrates with FortiGate firewalls through FortiLink.
Key Features
- 24 x Gigabit RJ-45 PoE+ ports
- 4 x Gigabit SFP ports
- 370 W PoE budget
- 56 Gbps switching throughput
- FortiLink management from FortiGate
- Rack mount
Product Information
Brand: Fortinet
Manufacturer: Fortinet
Product Line: Fortinet FortiSwitch
Model: 224D-FPOE
Product Type: Switch
Subcategory: Network hubs and switches
Packaged Quantity: 1
Color Category: White
Network and Communication
Switching Type: Gigabit Ethernet
Manageable: Yes
Remote Management: CLI, HTTP, HTTPS, SNMP 1, SNMP 2c, SNMP 3, SSH, Telnet, TFTP
Routing Protocol: BGP, OSPF
Authentication Method: RADIUS
Performance: Switching throughput: 56 Gbps
Capacity: Virtual interfaces (VLANs): 4000
MAC Address Table Size: 16000 entries
Jumbo Frame Support: Yes
Features: Flow control, Jumbo Frames support, Link Aggregation Control Protocol (LACP), LLDP support, Management Information Base (MIB), Multiple Spanning Tree Protocol (MSTP) support, Port mirroring, Power over Ethernet (PoE), Rapid Spanning Tree Protocol (RSTP) support, SNTP support, Spanning Tree Protocol (STP) support, Tagged VLAN
Connectivity
Ports: 24
Port Quantity: 24
Port Type: 10/100/1000 (PoE+)
Ports (2nd) Quantity: 4
Ports Type (2nd): Gigabit SFP
Interface Provided: 1 x console RJ-45, 1 x management (Gigabit LAN) RJ-45, 24 x 1000Base-T RJ-45 PoE+, 4 x Gigabit LAN SFP
Power Over Ethernet (PoE): PoE+
Power
Device Type: Internal power supply
Frequency: 50 - 60 hertz
Power Consumption Operational: 225 watt
PoE Budget: 370 watt
Technical Information
Min Operating Temperature: 32 degree Fahrenheit
Max Operating Temperature: 104 degree Fahrenheit
Operating Humidity: 10 - 90% (non-condensing)
Min Storage Temperature: -4 degree Fahrenheit
Max Storage Temperature: 158 degree Fahrenheit
Physical Characteristics
Form Factor (Hubs & Switches): Rack-mountable
Height (Rack Units): 1
Status Indicators: Link/activity, PoE, Power
Dimensions and Weight
Height: 1.7 inch
Width: 17.3 inch
Depth: 10.1 inch
Weight: 10.65 lbs
Certifications and Listing
Compliant Standards: C-Tick, CB, cUL, FCC Part 15 A, RoHS, UL, VCCI
Compliant Standards: IEEE 802.1ab (LLDP), IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad (LACP), IEEE 802.3af, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
ENERGY STAR Certified: No
EPEAT Compliant: No
TCO Certified: No
Warranty
Limited Warranty: Limited Lifetime
Service & Support Details: Limited warranty - lifetime
