Product Information
The Fortinet FortiSwitch 648F is a 1U managed Layer 3 campus switch, not a firewall. It has thirty two 1/2.5G RJ-45 ports, sixteen 100M/1/2.5/5G RJ-45 ports and eight 1/10/25G SFP28/SFP+ uplinks, plus management and console ports, 4 GB of RAM and two power supplies with front to back airflow. It supports 4,000 VLANs, 36,000 ACLs, 16,000 IPv4 routes and 56 link aggregation groups.
Key Features
- 32 x 2.5G + 16 x 5G RJ-45
- 8 x 25G SFP28 uplinks
- Layer 3 managed
- 4,000 VLANs
- Dual power supplies
- 1U rack mount
Product Information
Brand: Fortinet
Manufacturer: Fortinet
Product Line: Fortinet FortiSwitch
Model: 648F
Product Type: Switch
Subcategory: Network hubs and switches
Packaged Quantity: 1
Color Category: White
Network and Communication
Advanced Switching: Layer 3
Switching Type: 5 Gigabit Ethernet
Manageable: Yes
Remote Management: CLI, DHCP, HTTP, HTTPS, IPv4, IPv6, RMON, SNMP 1, SNMP 2c, SNMP 3, SSH, Syslog, Telnet, TFTP
Routing Protocol: BGP, Bidirectional Forwarding Detection (BFD), ECMP, IGMP, IS-IS, MLD, MSTP, OSPF, OSPFv2, PIM-SSM, Policy-based routing (PBR), RIP-2, URPF, VRRP
Authentication Method: Extensible Authentication Protocol (EAP), RADIUS
Performance: Latency: < 1 µs, Packets per second: 1071 Mpps, Switching capacity: 720 Gbps
Capacity: ACL: 36000, Host IPv4 routes: 192000, IP multicast entries: 12000, IPv4 routing entries: 16000, Link aggregation groups: 56, Packet buffer size: 8 MB, Spanning Tree Protocol instances: 32, Virtual interfaces (VLANs): 4000
MAC Address Table Size: 64K entries
Jumbo Frame Support: Yes
Features: 802.1x authentication, Access Control List (ACL) support, ARP inspection, Auto-negotiation, Automatic Media-Dependent Interface Crossover (MDIX), Automatic topology detection, DHCP relay, DHCP server, DHCP snooping, Encapsulated Remote SPAN (ERSPAN), FTP support, High Availability, IGMP proxy, IGMP querier, IGMP snooping, IP source guard, IP-MAC binding, Loop Guard, MAC Access Bypass (MAB), MAC black/whitelist, MACsec support, Media Dependent Interface (MDI), MLD proxy, MLD querier, MLD snooping, Network Access Control (NAC), Port mirroring, Port trunking, Precision Time Protocol (PTP), Private VLAN, Quality of Service (QoS), RA guard, Rapid PVST (RPVST), Remote Switch Port Analyzer (RSPAN), sFlow, SNTP support, SPAN mode, Storm Control, STP BPDU Guard, STP Root Guard, Time Domain Reflectometry (TDR), VLAN / port mapping, VLAN support, Wake On LAN (WOL)
Connectivity
Ports: 48
Port Quantity: 32
Port Type: 10/100/1000/2.5G
Ports (2nd) Quantity: 16
Ports Type (2nd): 100/1000/2.5G/5G
Ports (3rd) Quantity: 8
Interface Provided: 1 x console RJ-45, 1 x management (Gigabit LAN) RJ-45, 16 x 100/1000/2.5G/5GBase-T RJ-45, 32 x 1/2.5GBase-T RJ-45, 8 x 1/10/25GBase-X SFP28/SFP+
QSFP Slots: 10 Gigabit / 25 Gigabit SFP+ / SFP28
Power
Device Type: Internal power supply
Required Voltage: AC 100-240 volt
Frequency: 50/60 hertz
Power Provided: 350 watt
Power Supplies Installed: 2
Power Supplies Supported: 2
Hot-Plug: Hot-plug
Memory and Processor
RAM Installed: 4 GB
Memory Technology: DDR4 SDRAM
Flash Memory Installed: 32 megabyte
Physical Characteristics
Form Factor (Hubs & Switches): Rack-mountable
Height (Rack Units): 1
Airflow Direction: Front to back airflow
Status Indicators: Alarm, Fan, Link/activity/speed, Power
Rack Mounting Kit: Included
Dimensions and Weight
Height: 1.7 inch
Width: 17.3 inch
Depth: 13.8 inch
Weight: 15.76 lbs
Included Items
Included Accessories: 4 rubber feet
Cables: 1 x console cable, 2 x AC power cable
Certifications and Listing
Compliant Standards #2: BSMI, CB, FCC, RCM, RoHS 2, UL, VCCI
Compliant Standards: IEEE 802.1ab (LLDP), IEEE 802.1ad, IEEE 802.1ae, IEEE 802.1AX, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1Qbb, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ae, IEEE 802.3az, IEEE 802.3ba, IEEE 802.3bj, IEEE 802.3bm, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Compliant Standards: BSMI, CB, FCC, RCM, RoHS 2, UL, VCCI
ENERGY STAR Certified: No
EPEAT Compliant: No
TCO Certified: No
Warranty
Service Activation: No
Not sure this is the right security appliance for your site? Send us your user count, internet speed and current firewall model and the DatorPro team will help you confirm the fit before you order.
