Product Information
This FortiWiFi 30G bundle comes with 1 year of FortiCare Premium support and 1 year of FortiGuard Unified Threat Protection. The 30G is a small desktop firewall with built in Wi-Fi 6, rated at 4 Gbps firewall (1518-byte UDP), 830 Mbps application control and 800 Mbps IPS, with up to 600,000 TCP sessions, 2,000 policies and 250 client to gateway tunnels. It has one WAN, one FortiLink and two Gigabit LAN ports, three antennas and a console, drawing about 11.3 W. The description quotes 400 Mbps firewall, which does not match the spec.
Key Features
- 1 yr FortiCare Premium + UTP
- Built in Wi-Fi 6
- 4 Gbps firewall (1518-byte UDP)
- 600,000 TCP sessions
- 1 WAN + 1 FortiLink + 2 LAN
- Desktop, cloud managed
Product Information
Brand: Fortinet
Manufacturer: Fortinet
Product Line: Fortinet FortiWiFi
Model: 30G
Product Type: Security appliance
Packaged Quantity: 1
Color Category: White
Country: American Samoa, Argentina, Aruba, Bahamas, Bermuda, Canada, Cayman Islands, Dominican Republic, Guam, Haiti, Mariana Islands, Marshall Islands, Nicaragua, Palau, Puerto Rico, Saint Kitts and Nevis, Saint Lucia, Saint Vincent, United States, Virgin Islands
Network and Communication
Connectivity Technology: Wired, Wireless
Data Link Protocols: Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11a, IEEE 802.11ac Wave 2, IEEE 802.11ax (Wi-Fi 6), IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Network Standard: DNS, HTTP, HTTPs, IPSec, IPv4, IPv6, TCP/IP, UDP
Remote Management: DNS, HTTP, HTTPS, IPv4, IPv6, TCP/IP, UDP
Encryption: 256-bit AES, 256-bit SHA, SSL, TLS 1.3
Capacity: Client to gateway IPSec VPN tunnels: 250, Concurrent TCP sessions (enterprise traffic mix): 600000, Firewall policies: 2000, Gateway to gateway IPSec VPN Tunnels: 200, Maximum number of FortiTokens: 500, New TCP sessions per second: 30000, Number of FortiAP devices (tunnel mode): 8, Number of FortiAP devices: 16, Number of FortiSwitches: 8, SSL inspection concurrent sessions: 55000, SSL inspection CPS: 260
Wireless LAN: 802.11a/b/g/n/ac Wave 2/ax
Network Band: 2.4 GHz, 5 GHz
Network Device: Application control throughput (HTTP 64K): 830 Mbps, Firewall latency (64-byte UDP): 2.87 µs, Firewall throughput: 5.85 Mpps, IPS throughput (enterprise traffic mix): 800 Mbps, IPv4 firewall throughput (1518-byte UDP): 4 Gbps, IPv4 firewall throughput (512-byte UDP): 4 Gbps, IPv4 firewall throughput (64-byte UDP): 3.9 Gbps, IPv6 firewall throughput (1518-byte UDP): 4 Gbps, IPv6 firewall throughput (512-byte UDP): 4 Gbps, IPv6 firewall throughput (64-byte UDP): 3.9 Gbps, NGFW throughput (enterprise traffic mix): 570 Mbps, SSL inspection throughput: 400 Mbps, Threat protection throughput (enterprise traffic mix): 500 Mbps, VPN throughput (512-bit IPSec): 3.5 Gbps
Antennas: 3
Antenna Form Factor: External detachable
Operating System Edition: FortiOS
Features: Advanced sandbox detection, AI/ML powered, Anti-malware protection, Built-in ASIC, Data Loss Prevention (DLP), DDoS Protection, DNS filtering, Firewall protection, High Availability, Intrusion Prevention System (IPS), NGFW appliance, Reset button, SD-WAN support, Self-healing network, SSL inspection, Trusted Platform Module (TPM), URL protection, VPN support, Wall mountable, Zero Trust Network Access (ZTNA)
Bundled Services: 1 year FortiCare Premium Support + 1 year FortiGuard Unified Threat Protection (UTP)
Connectivity
Ports: 4
Interface Provided: 1 x 1000Base-T - RJ-45 (WAN), 1 x 1000Base-T (FortiLink) - RJ-45, 1 x console - RJ-45, 2 x 1000Base-T - RJ-45, 3 x antenna
Power
Device Type: External power adapter
Required Voltage: AC 100-240 volt
Frequency: 50/60 hertz
Power Consumption Operational: 11.3 watt
Memory and Processor
Processor Brand: Fortinet
Processor Type: FortiASIC SOC4
Technical Information
Min Operating Temperature: 32 degree Fahrenheit
Max Operating Temperature: 104 degree Fahrenheit
Operating Humidity: 20 - 90% (non-condensing)
Physical Characteristics
Form Factor: Desktop
Status Indicators: HA, Power, Status, Wi-Fi
Dimensions and Weight
Height: 1.6 inch
Width: 5.6 inch
Depth: 6.3 inch
Weight: 24.69 ounce
Certifications and Listing
Compliant Standards: IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Warranty
Service Activation: No
