Product Information
The Fortinet FortiWiFi 60F is a fanless desktop firewall and SD-WAN appliance with built in Wi-Fi 5 (802.11ac Wave 2). It is rated at 10 Gbps firewall, 1.4 Gbps IPS, 1 Gbps NGFW and 6.5 Gbps IPsec VPN, with up to 700,000 concurrent sessions, 5,000 policies and 200 IPsec tunnels. It has three WAN/DMZ ports, seven Gigabit LAN ports, two FortiLink ports, a console and USB 3.0, drawing about 18.7 W.
Key Features
- Built in Wi-Fi 5
- 10 Gbps firewall
- 1 Gbps NGFW
- 700,000 concurrent sessions
- 3 WAN/DMZ + 7 LAN + 2 FortiLink
- Fanless desktop
Product Information
Brand: Fortinet
Manufacturer: Fortinet
Product Line: Fortinet FortiWiFi
Model: 60F
Product Type: Security appliance
Packaged Quantity: 1
Color Category: White
Network and Communication
Connectivity Technology: Wired, Wireless
Data Link Protocols: Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11a, IEEE 802.11ac Wave 2, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Network Standard: IPSec
Encryption: SSL, TLS 1.3
Capacity: Concurrent sessions: 700000, Firewall policies: 5000, IPSec VPN tunnels: 200, Latency: 4 µs, New sessions: 35000, Number of FortiSwitches: 16, Number of FortiToken devices: 500, Virtual domains: 10
Wireless LAN: 802.11a/b/g/n/ac Wave 2
Network Band: 2.4 GHz, 5 GHz
Network Device: Application control (AVC) throughput: 1.8 Gbps, Firewall throughput (1518-byte UDP): 10 Gbps, Firewall throughput (512-byte UDP): 10 Gbps, Firewall throughput (64-byte UDP): 6 Gbps, Firewall throughput: 10 Gbps, Firewall throughput: 9 Mpps, IPS throughput: 1.4 Gbps, NGFW throughput: 1 Gbps, SSL inspection throughput: 900 Mbps, Threat protection throughput: 700 Mbps, VPN throughput (512-bit IPSec): 6.5 Gbps
Operating System Edition: FortiOS
Features: Antivirus analysis, Application filtering, CAPWAP support, Fanless, Firewall protection, Intrusion Prevention System (IPS), IPSec Virtual Private Network (VPN), Web threat protection
Connectivity
Interface Provided: 1 x console - RJ-45, 1 x USB 3.0 - Type A, 2 x FortiLink - RJ-45, 3 x 1000Base-T - RJ-45 (WAN / DMZ), 7 x 1000Base-T - RJ-45
Power
Device Type: External power adapter
Frequency: 50/60 hertz
Power Consumption Operational: 18.7 watt
Power Supplies Installed: 1
Memory and Processor
Processor Brand: Fortinet
Processor Type: FortiASIC SOC4
Processors Installed: 1
Technical Information
Min Operating Temperature: 32 degree Fahrenheit
Max Operating Temperature: 104 degree Fahrenheit
Operating Humidity: 10 - 90% (non-condensing)
Physical Characteristics
Form Factor: Desktop
Status Indicators: Link/activity
Dimensions and Weight
Height: 1.5 inch
Width: 8.5 inch
Depth: 6.3 inch
Weight: 2.23 lbs
Certifications and Listing
Compliant Standards #2: C-Tick, CB, cUL, FCC Part 15 Class B, UL, VCCI
Compliant Standards: IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Compliant Standards: C-Tick, CB, cUL, FCC Part 15 Class B, UL, VCCI
ENERGY STAR Certified: No
EPEAT Compliant: No
TCO Certified: No
Warranty
Service Activation: No
Not sure this is the right security appliance for your site? Send us your user count, internet speed and current firewall model and the DatorPro team will help you confirm the fit before you order.
