Product Information
This FortiWiFi 61F bundle comes with 1 year of 24x7 FortiCare support and 1 year of FortiGuard Unified Threat Protection. The 61F is a fanless desktop firewall with built in Wi-Fi 5 (802.11ac Wave 2) and 128 GB of storage, rated at 10 Gbps firewall (1518-byte UDP), 1.4 Gbps IPS, 1 Gbps NGFW and 6.5 Gbps IPsec VPN, with up to 700,000 TCP sessions. It has two WAN ports, a DMZ port, two FortiLink ports, five Gigabit LAN ports, a console and USB 3.0.
Key Features
- 1 yr 24x7 FortiCare + UTP
- Built in Wi-Fi 5
- 128 GB local storage
- 10 Gbps firewall (1518-byte UDP)
- 2 WAN + DMZ + 2 FortiLink + 5 LAN
- Fanless desktop
Product Information
Brand: Fortinet
Manufacturer: Fortinet
Product Line: Fortinet FortiWiFi
Model: 61F
Product Type: Security appliance
Packaged Quantity: 1
Color Category: White
Network and Communication
Connectivity Technology: Wired, Wireless
Data Link Protocols: Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11a, IEEE 802.11ac Wave 2, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Network Standard: HTTPs, IPSec
Remote Management: HTTPS
Encryption: 256-bit AES, 256-bit SHA, SSL, TLS 1.3
Capacity: Client to gateway IPSec VPN tunnels: 500, Concurrent SSL VPN users: 200, Concurrent TCP sessions: 700000, Firewall policies: 5000, Gateway to gateway IPSec VPN Tunnels: 200, Maximum virtual domains: 10, New TCP sessions per second: 35000, Number of FortiAP devices (tunnel mode): 32, Number of FortiAP devices: 64, Number of FortiSwitches: 16, Number of FortiToken devices: 500, SSL inspection concurrent sessions: 55000, SSL inspection CPS: 400, Virtual domains: 10
Wireless LAN: 802.11a/b/g/n/ac Wave 2
Network Band: 2.4 GHz, 5 GHz
Network Device: Application control (AVC) throughput: 1.8 Gbps, CAPWAP throughput: 8 Gbps, Firewall latency (64-byte UDP): 3.3 µs, Firewall throughput (1518-byte UDP): 10 Gbps, Firewall throughput (512-byte UDP): 10 Gbps, Firewall throughput (64-byte UDP): 6 Gbps, Firewall throughput: 9 Mpps, IPS throughput: 1.4 Gbps, NGFW throughput: 1 Gbps, SSL inspection throughput: 630 Mbps, Threat protection throughput: 700 Mbps, VPN throughput (512-bit IPSec): 6.5 Gbps, VPN throughput (SSL): 900 Mbps
Operating System Edition: FortiOS
Features: 3G/4G USB Dongle Support, Fanless, FortiLink Mode, SD-WAN support
Bundled Services: 1 year 24x7 FortiCare Support + 1 year FortiGuard Unified Threat Protection (UTP)
Connectivity
Interface Provided: 1 x 1000Base-T - RJ-45 (DMZ), 1 x console - RJ-45, 1 x USB 3.0 - Type A, 2 x 1000Base-T - RJ-45 (WAN), 2 x FortiLink - RJ-45, 5 x 1000Base-T - RJ-45
Power
Device Type: External power adapter
Memory and Processor
Processor Brand: Fortinet
Processor Type: FortiASIC SOC4
Processors Installed: 1
Hard Drive Capacity: 128 GB
Port Expansion Hard Drive Type: SSD
Technical Information
Min Operating Temperature: 32 degree Fahrenheit
Max Operating Temperature: 104 degree Fahrenheit
Operating Humidity: 10 - 90% (non-condensing)
Physical Characteristics
Form Factor: Desktop
Status Indicators: Status
Installed Quantity: 1
Dimensions and Weight
Height: 1.5 inch
Width: 8.5 inch
Depth: 6.3 inch
Weight: 2.23 lbs
Certifications and Listing
Compliant Standards: IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Warranty
Service Activation: No
