Product Information
This FortiWiFi 70G-POE bundle comes with 5 years of FortiCare Premium support and 5 years of FortiGuard Unified Threat Protection. It is a desktop firewall with built in Wi-Fi 6, Bluetooth LE, three detachable antennas and four PoE+ ports (30 W each), rated at 10 Gbps firewall (1518-byte UDP), 2.5 Gbps IPS and 1.5 Gbps NGFW, with up to 1.4 million TCP sessions. It has two WAN ports, two FortiLink ports, two Gigabit LAN ports, four PoE+ ports, a console and USB. The description mentions a 60 W PoE budget.
Key Features
- 5 yr FortiCare Premium + UTP
- Built in Wi-Fi 6
- 4 x PoE+ ports
- 10 Gbps firewall (1518-byte UDP)
- 1.5 Gbps NGFW
- Desktop, cloud managed
Product Information
Brand: Fortinet
Manufacturer: Fortinet
Product Line: Fortinet FortiWiFi
Model: 70G-POE
Product Type: Security appliance
Packaged Quantity: 1
Color Category: White
Country: American Samoa, Argentina, Aruba, Bahamas, Bermuda, Canada, Cayman Islands, Dominican Republic, Guam, Haiti, Marshall Islands, Nicaragua, Northern Mariana Islands, Palau, Puerto Rico, Saint Kitts and Nevis, Saint Lucia, Saint Vincent, United States, Virgin Islands
Network and Communication
Connectivity Technology: Wired, Wireless
Data Link Protocols: Bluetooth LE, Gigabit Ethernet, IEEE 802.11a, IEEE 802.11ac Wave 2, IEEE 802.11ax (Wi-Fi 6), IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Network Standard: HTTP, HTTPs, IPSec, IPv6, TCP/IP, UDP/IP
Remote Management: HTTP, HTTPS
Encryption: 256-bit AES, 256-bit SHA, SSL, TLS 1.3
Capacity: Client to gateway IPSec VPN tunnels: 500, Concurrent TCP sessions: 1400000, Firewall policies: 5000, Gateway to gateway IPSec VPN Tunnels: 200, Maximum virtual domains: 10, New TCP sessions per second: 100000, Number of FortiAP devices (tunnel mode): 48, Number of FortiAP devices: 96, Number of FortiSwitches: 24, Number of FortiToken devices: 500, SSL inspection concurrent sessions: 140000, SSL inspection CPS: 715, Virtual domains: 10
Wireless LAN: 802.11a/b/g/n/ac Wave 2/ax, Bluetooth LE
Network Band: 2.4 GHz, 5 GHz
Network Device: Application control throughput (HTTP 64K): 3.6 Gbps, CAPWAP Throughput (HTTP 64K): 6.8 Gbps, Firewall latency (64-byte UDP): 2.46 µs, Firewall throughput (1518-byte UDP): 10 Gbps, Firewall throughput (512-byte UDP): 10 Gbps, Firewall throughput (64-byte UDP): 10 Gbps, Firewall throughput: 15 Mpps, IPS throughput (enterprise traffic mix): 2.5 Gbps, NGFW throughput (enterprise traffic mix): 1.5 Gbps, SSL inspection throughput: 1.4 Gbps, Threat protection throughput (enterprise traffic mix): 1.3 Gbps, VPN throughput (512-bit IPSec): 7.1 Gbps
Antennas: 3
Antenna Form Factor: External detachable
Operating System Edition: FortiOS
Features: 60W PoE power budget, AI powered, Built-in ASIC, Fanless, Firewall protection, High Availability, Intrusion Prevention System (IPS), SD-WAN support, Self-healing network, Signed firmware, SSL inspection, Trusted Platform Module (TPM), VPN support, Zero Trust Network Access (ZTNA)
Bundled Services: 5 years FortiCare Premium Support + 5 years FortiGuard Unified Threat Protection (UTP)
Connectivity
Ports: 10
Interface Provided: 1 x console - RJ-45, 1 x USB - Type A, 2 x 1000Base-T - RJ-45, 2 x 1000Base-T - RJ-45 (WAN), 2 x 1000Base-T (FortiLink) - RJ-45, 3 x antenna - SMA, 4 x 1000Base-T (PoE+) - RJ-45 - 30 W
Power Over Ethernet (PoE): PoE+
Power
Device Type: External power adapter
Required Voltage: AC 100-240 volt
Frequency: 50/60 hertz
Power Consumption Operational: 74.9 watt
80 PLUS Certification: 80 PLUS
Memory and Processor
Processor Brand: Fortinet
Processor Type: FortiASIC SP5
Processors Installed: 1
Technical Information
Min Operating Temperature: 32 degree Fahrenheit
Max Operating Temperature: 104 degree Fahrenheit
Operating Humidity: 10 - 90% (non-condensing)
Physical Characteristics
Form Factor: Desktop
Status Indicators: Bluetooth Low Energy (BLE), Firmware, HA, Link/activity, PoE activity, PoE max, Power, Status, WAN, Wi-Fi
Dimensions and Weight
Height: 1.6 inch
Width: 8.5 inch
Depth: 6.3 inch
Weight: 2.36 lbs
Certifications and Listing
Compliant Standards: IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3at
Warranty
Service Activation: No
