Product Information
This FortiWiFi 80F-2R bundle comes with 3 years of FortiCare Premium support and 3 years of FortiGuard Enterprise Protection. The 80F-2R is a fanless firewall with built in dual radio Wi-Fi 6 (up to 574 Mbps on 2.4 GHz and 1201 Mbps on 5 GHz) and Bluetooth LE, for desk, wall or rack use. It is rated at 10 Gbps firewall (1518-byte UDP), 1.4 Gbps IPS and 1 Gbps NGFW, with up to 1.5 million TCP sessions. It has six Gigabit LAN ports, two FortiLink ports, two RJ-45/SFP combo WAN ports and three SMA antenna connectors.
Key Features
- 3 yr Premium + Enterprise Protection
- Dual radio Wi-Fi 6
- 10 Gbps firewall (1518-byte UDP)
- 1.5M TCP sessions
- 6 LAN + 2 FortiLink + 2 combo
- Fanless, desk/wall/rack
Product Information
Brand: Fortinet
Manufacturer: Fortinet
Product Line: Fortinet FortiWiFi
Model: 80F-2R
Product Type: Security appliance
Packaged Quantity: 1
Color Category: White
Country: American Samoa, Argentina, Aruba, Bahamas, Bermuda, Canada, Cayman Islands, Dominican Republic, Guam, Haiti, Mariana Islands, Marshall Islands, Nicaragua, Palau, Puerto Rico, Saint Kitts and Nevis, Saint Lucia, Saint Vincent, United States, Virgin Islands
Network and Communication
Connectivity Technology: Wired, Wireless
Data Link Protocols: Bluetooth LE, Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax (Wi-Fi 6), IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Network Standard: HTTP, HTTPs, IPSec, IPv4, IPv6, TCP/IP, UDP/IP
Remote Management: HTTP, HTTPS
Encryption: 256-bit AES, 256-bit SHA, SSL, TLS 1.3
Capacity: Client to gateway IPSec VPN tunnels: 2500, Concurrent SSL VPN users: 200, Concurrent TCP sessions: 1500000, Firewall policies: 5000, Gateway to gateway IPSec VPN Tunnels: 200, Maximum virtual domains: 10, New TCP sessions per second: 45000, Number of FortiAP devices (tunnel mode): 48, Number of FortiAP devices: 96, Number of FortiSwitches: 24, Number of FortiToken devices: 500, SSL inspection concurrent sessions: 100000, SSL inspection CPS: 700, Virtual domains: 10
Wireless LAN: 802.11a/b/g/n/ac/ax, Bluetooth LE
Network Band: 2.4 GHz, 5 GHz
Network Device: Application control throughput: 1.8 Gbps, CAPWAP throughput: 9 Gbps, Firewall latency (64-byte UDP): 3.23 µs, Firewall throughput (1518-byte UDP): 10 Gbps, Firewall throughput (512-byte UDP): 10 Gbps, Firewall throughput (64-byte UDP): 7 Gbps, Firewall throughput: 10.5 Mpps, IPS throughput (enterprise traffic mix): 1.4 Gbps, Maximum data rate (2.4 GHz): 574 Mbps, Maximum data rate (5 GHz): 1201 Mbps, NGFW throughput (enterprise traffic mix): 1 Gbps, SSL inspection throughput: 715 Mbps, Threat protection throughput (enterprise traffic mix): 900 Mbps, VPN throughput (512-bit IPSec): 6.5 Gbps, VPN throughput (SSL): 950 Mbps
Antennas: 3
Antenna Form Factor: External detachable
Features: 2x2 MIMO technology, AI powered, CAPWAP support, Intrusion Detection and Prevention (IDP), SD-WAN support, SSL inspection, Trusted Platform Module (TPM), VPN support, Zero Trust Network Access (ZTNA)
Bundled Services: 3 years FortiCare Premium Support + 3 years FortiGuard Enterprise Protection
Connectivity
Interface Provided: 1 x console - RJ-45, 1 x USB 3.0 - Type A, 2 x 1000Base-T (FortiLink) - RJ-45, 2 x 1000Base-T/1000Base-X - RJ-45/SFP (mini-GBIC) (WAN), 3 x antenna - SMA, 6 x 1000Base-T - RJ-45
Power
Device Type: External power adapter
Required Voltage: AC 115/230 volt
Frequency: 50/60 hertz
Power Consumption Operational: 22.9 watt
Power Supplies Installed: 1
Power Supplies Supported: 2
Redundant Power Supply: Optional
Memory and Processor
Processor Brand: Fortinet
Processor Type: FortiASIC SOC4
Processors Installed: 1
Technical Information
Min Operating Temperature: 32 degree Fahrenheit
Max Operating Temperature: 104 degree Fahrenheit
Operating Humidity: 10 - 90% (non-condensing)
Physical Characteristics
Form Factor: Desktop / wall / rack mountable
Status Indicators: HA, Link/activity, Power, SFP, Status, WAN, Wi-Fi
Dimensions and Weight
Height: 2.4 inch
Width: 8.5 inch
Depth: 7 inch
Weight: 3.31 lbs
Included Items
Cables: 1 x network cable
Certifications and Listing
Compliant Standards: IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, Wi-Fi CERTIFIED 6
Warranty
Service Activation: No
Not sure this is the right security appliance for your site? Send us your user count, internet speed and current firewall model and the DatorPro team will help you confirm the fit before you order.
