Product Information
This FortiWiFi 81F-2R-3G4G-POE bundle (FWF-81F-2R-3G4G-POE-ABDL809-36) comes with 3 years of FortiCare Premium support and 3 years of FortiGuard Enterprise Protection. It is a desktop or wall mount firewall with dual radio Wi-Fi 6, a 3G/4G LTE modem, PoE+ ports, Bluetooth LE and 128 GB of storage, rated at 5 Gbps firewall, 1 Gbps IPS and 800 Mbps NGFW, with up to 700,000 TCP sessions and 250 client to gateway tunnels. It has an optional second power supply.
Key Features
- 3 yr Premium + Enterprise Protection
- Dual radio Wi-Fi 6
- Built in 3G/4G LTE
- PoE+ ports
- 5 Gbps firewall
- 128 GB local storage
Product Information
Brand: Fortinet
Manufacturer: Fortinet
Product Line: Fortinet FortiWiFi
Model: 81F-2R-3G4G-POE
Product Type: Security appliance
Packaged Quantity: 1
Country: American Samoa, Argentina, Aruba, Bahamas, Bermuda, Canada, Cayman Islands, Dominican Republic, Guam, Haiti, Mariana Islands, Marshall Islands, Nicaragua, Palau, Puerto Rico, Saint Kitts and Nevis, Saint Lucia, Saint Vincent, United States, Virgin Islands
Network and Communication
Connectivity Technology: Wired, Wireless
Data Link Protocols: Bluetooth LE, Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax (Wi-Fi 6), IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Network Standard: HTTP, HTTPs, IPSec, IPv4, TCP/IP, UDP/IP
Remote Management: HTTP, HTTPS
Encryption: 256-bit AES, 256-bit SHA, SSL, TLS 1.3
Capacity: Client to gateway IPSec VPN tunnels: 250, Concurrent SSL VPN users: 200, Concurrent TCP sessions: 700000, Firewall policies: 5000, Gateway to gateway IPSec VPN Tunnels: 200, Maximum virtual domains: 10, New TCP sessions per second: 35000, Number of FortiAP devices (tunnel): 8, Number of FortiAP devices: 16, Number of FortiSwitches: 8, Number of FortiToken devices: 500, SSL inspection concurrent sessions: 55000, SSL inspection CPS: 320, Virtual domains: 10
Wireless LAN: 802.11a/b/g/n/ac/ax, Bluetooth LE
Network Band: 2.4 GHz, 5 GHz
Cellular Data Connectivity Technology: HSPA+, LTE, UMTS
Mobile Broadband Access: Yes
Cellular Band: UMTS/HSPA+ B1/B2/B4/B5/B6/B8/B9/B19 / LTE B1/B2/B3/B4/B5/B7/B8/B9/B12/B13/B18/B19/B20/B26/B28/B29/B30/B32/B41/B42/B43/B46/B48/B66
Network Device: Application control throughput: 990 Mbps, CAPWAP throughput: 3.5 Gbps, Firewall latency (64-byte UDP): 2.97 µs, Firewall throughput (1518/512/64-byte UDP): 5 Gbps, Firewall throughput: 7.5 Mpps, IPS throughput (enterprise traffic mix): 1 Gbps, Maximum data rate (2.4 GHz): 450 Mbps, Maximum data rate (5 GHz): 1300 Mbps, NGFW throughput (enterprise traffic mix): 800 Mbps, SSL inspection throughput: 310 Mbps, Threat protection throughput (enterprise traffic mix): 600 Mbps, VPN throughput (512-bit IPSec): 4.4 Gbps, VPN throughput (SSL): 490 Mbps
Antennas: 6
Antenna Form Factor: External detachable
Operating System Edition: FortiOS
Features: 3G/4G USB Dongle Support, 3x3 MIMO technology, 96W PoE power budget, GNSS Bias, SD-WAN support, SSL inspection, Trusted Platform Module (TPM), VPN support
Connectivity
Expansion Slots: 2 (total) / 2 (free) x Nano SIM card
Power Over Ethernet (PoE): PoE+
Power
Device Type: External power adapter
Required Voltage: AC 100-240 volt
Frequency: 50/60 hertz
Power Consumption Operational: 109.3 watt
Power Supplies Installed: 1
Power Supplies Supported: 2
Redundant Power Supply: Optional
Memory and Processor
Processor Brand: Fortinet
Processor Type: FortiASIC SOC4
Processors Installed: 1
Hard Drive Capacity: 128 GB
Port Expansion Hard Drive Type: SSD
Technical Information
Min Operating Temperature: 32 degree Fahrenheit
Max Operating Temperature: 104 degree Fahrenheit
Operating Humidity: 20 - 90% (non-condensing)
Physical Characteristics
Form Factor: Desktop/Wall Mountable
Status Indicators: 3G/4G, HA, Link/activity, PoE activity, PoE max, Power, Service, SFP, Status, WAN, Wi-Fi
Installed Quantity: 1
Included Items
Cables: 1 x network cable
Certifications and Listing
Compliant Standards: IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3at, Wi-Fi CERTIFIED 6
Warranty
Service Activation: No
