Product Information
The Hanwha Vision WiseNet SPO-6011 is a 60 W PoE++ injector with a Gigabit RJ-45 input and an SFP slot. It outputs 55 V, operates from -40 to 131 °F, is IP40 rated and wall mountable, and is listed for WiseNet X Plus cameras like the XNP-6400R.
Key Features
- 1 x PoE++ RJ-45 output, up to 60 W
- Gigabit RJ-45 and SFP inputs
- 55 V output, AC 100-240 V input
- Operating range -40 to 131 °F
- IP40, wall mountable, LED
Product Information
Brand: Hanwha Techwin
Manufacturer: Hanwha
Product Line: Hanwha Vision WiseNet
Model: SPO-6011
Product Type: PoE Injector
Subcategory: Power converters, splitters and accessories
Packaged Quantity: 1
Color: Black
Color Category: Black
Network and Communication
Features: LED Indicator, Wall Mountable
Connectivity
Interface Provided: 1 x - SFP (mini-GBIC), 1 x Gigabit LAN - RJ-45
Power Over Ethernet (PoE): PoE++
Output Connector Quantity: 1
Power
Required Voltage: AC 100-240 volt
Frequency: 50/60 hertz
Power Output Connectors Details: 1 x RJ-45
Power Provided: 60 watt
Form Factor (Power Device): External
Max Input Current: 1.1 ampere
Provided Voltage: 55 volt
Technical Information
Min Operating Temperature: -40 degree Fahrenheit
Max Operating Temperature: 131 degree Fahrenheit
Operating Humidity: 20 - 90% (non-condensing)
Dimensions and Weight
Height: 1.6 inch
Width: 3.3 inch
Depth: 8.6 inch
Weight: 16.93 ounce
Certifications and Listing
Compliant Standards: IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IP40, PoE++, RoHS, WEEE
Compliant Standards: IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at
ENERGY STAR Certified: No
Warranty
Service Activation: No
