Product Information
The Hanwha Vision Wisenet Q QNV-8080R is a 5 MP dome recording 2592 x 1944 at 30 fps with a 1/2.8 inch sensor and 3.1 to 10 mm motorized lens (3.1x). IR reaches 66 ft, it streams H.265, H.264 and MJPEG, has composite out and alarm I/O, and runs on PoE Class 3 at 8.9 W. White.
Key Features
- 5 MP, 2592 x 1944 at 30 fps
- 3.1 to 10 mm motorized
- IR up to 66 ft
- H.265, H.264, MJPEG
- Composite out, alarm I/O
- PoE Class 3, white
Product Information
Brand: Hanwha Techwin
Manufacturer: Hanwha
Product Line: Hanwha Vision WiseNet Q
Model: QNV-8080R
Packaged Quantity: 1
Color: White
Color Category: White
Network and Communication
Connectivity Technology: Wired
Operating System Required: Apple macOS 10.12, Apple MacOS X 10.10, Apple MacOS X 10.11, Microsoft Windows 7, Windows 10, Windows 8.1
Features: Auto gain control, Auto white balance, Backlight Compensation (BLC), Constant Bit Rate (CBR), Defocus Detection, Direction detection, IP address filtering, Lens Distortion Compensation (LDC), Motion Detection, Multicast Streaming, ONVIF (Profile G) support, ONVIF (Profile S) support, ONVIF (Profile T) support, Privacy Mask Function, Samsung Super Dynamic Range (SSDR), Samsung Super Noise Reduction (SSNR), Variable Bit Rate (VBR), Wide Dynamic Range (WDR), WiseStream II support
Connectivity
Network Interface: Ethernet 10Base-T/100Base-TX
Protocols: ARP, Bonjour, DDNS, DHCP, DNS, FTP, HTTP, HTTPS, ICMP, IGMP, IPv4, IPv6, LLDP, NTP, QOS, RTCP, RTP, RTSP, SMTP, SNMP 1, SNMP 2c, SNMP 3, SSL, TCP/IP, TLS, UDP/IP, UPnP
Ports: Composite video, LAN/power - RJ-45
Power
Low Voltage Power: PoE Class 3
Power Consumption Operational: 8.9 watt
Memory and Processor
Memory Cards Supported: microSD Card, microSDHC Card, microSDXC Card
Technical Information
Angular Field of View (D, Max, Degree): 133.1
Angular Field of View (H, Max, Degree): 100.3
Angular Field of View (V, Max, Degree): 72.3
Infrared Distance: 66 ft
Infrared LEDs: Yes
Video Signals: Composite video
Angular Field of View (D, Min, Degree): 38.8
Max Focal Length: 10 millimetre
Optical Zoom: 3.1
Sensor Pixels Effective (H): 2592
Sensor Pixels Effective (V): 1944
Alarm Input Quantity: 1
Alarm Output Quantity: 1
Tilt: 0 to 67
Motion Detection: Yes
Panning Range (degree): 350
Angular Field of View (H, Min, Degree): 31.2
Angular Field of View (V, Min, Degree): 23.5
Minimum Illumination: 0 lux - B&W - infrared LEDs on, 0.15 lux - color - F2.0
Total Pixels: 5,000,000 pixels
Image Sensor Size: 1/2.8"
Image Sensor Type: CMOS
Lens Aperture: F/1.6-2.9
Min Focal Length: 3.1 millimetre
Sensor Size (metric): 9.1 mm (1/2.8")
Digital Video Capture Resolution: 1280 x 720, 1280 x 960, 1920 x 1080, 2592 x 1944, 640 x 360, 640 x 480, 720 x 480, 720 x 576, 800 x 448, 800 x 600
Max Frame Rate: 30 frames per second
Shutter Speed (Max): 1/12000 second (time unit)
Shutter Speed (Min): 1/5 second (time unit)
Focal Length Control: Motorized zoom
Video Formats: H.264, H.265, MJPEG, NTSC, PAL
Video Input: Color
Touchscreen: No
Max Video Resolution: 2592 x 1944
Min Operating Temperature: -22 degree Fahrenheit
Max Operating Temperature: 131 degree Fahrenheit
Operating Humidity: 0 - 90%
Physical Characteristics
Form Factor: Dome
Camera Mechanical Design: Fixed
Dimensions and Weight
Height: 4.2 inch
Width: 5.4 inch
Depth: 5.4 inch
Weight: 24.69 ounce
Not sure this camera fits your setup? Send us the model of your NVR, VMS or current cameras and how you plan to mount and power it, and the DatorPro team will help you confirm compatibility before you order.
