Product Information
The Hanwha Vision Wisenet X XNV-6011 is a 2 MP outdoor dome recording 1080p at up to 60 fps through a 2.8 mm lens with a 112 degree view. It has defog, image stabilization and composite out, and runs on PoE at 6.5 W. SmartViewer software supported.
Key Features
- 2 MP, up to 60 fps
- 2.8 mm, 112 degree view
- Defog
- Image stabilization
- Composite out
- PoE, 6.5 W
Product Information
Brand: Hanwha Techwin
Manufacturer: Hanwha
Product Line: Hanwha Vision WiseNet X
Model: XNV-6011
Packaged Quantity: 1
Network and Communication
Connectivity Technology: Wired
Operating System Required: Apple macOS 10.12, Apple MacOS X 10.10, Apple MacOS X 10.11, Microsoft Windows 7, Windows 10, Windows 8.1
Features: 2D Digital Noise Reduction Technology, 3D Noise Filtering, Auto gain control, Auto white balance, Backlight Compensation (BLC), Constant Bit Rate (CBR), Defocus Detection, Defog, Digital Image Stabilization (DIS), Digital PTZ function, Face Detection, Highlight Compensation (HLC), Image flip, Image mirror, Lens Distortion Compensation (LDC), Motion Detection Technology, Multicast Streaming, ONVIF (Profile G) support, ONVIF (Profile S) support, Pixel Counter Support, Privacy Mask Function, Progressive scanning, Samsung Super Dynamic Range (SSDR), Samsung Super Noise Reduction (SSNRV), Smart Codec, Tamper-detection, Variable Bit Rate (VBR), Video analytics, Wide Dynamic Range (WDR), WiseStream II support
Software Type: SmartViewer
Connectivity
Network Interface: Ethernet 10Base-T/100Base-TX
Protocols: ARP, Bonjour, DDNS, DHCP, DNS, EAP, FTP, HTTP, HTTPS, ICMP, IGMP, IPv4, IPv6, NTP, PIM-SM, PPPoE, QOS, RTCP, RTP, RTSP, SMTP, SNMP 1, SNMP 2c, SNMP 3, SSL, SSM, TCP/IP, TLS, UDP/IP, UPnP
Ports: Composite video, LAN/power - RJ-45, USB - Micro-USB Type B
Power
Low Voltage Power: PoE
Power Consumption Operational: 6.5 watt
Memory and Processor
Memory Cards Supported: SD Memory Card, SDHC Memory Card, SDXC Memory Card
Technical Information
Focus Modes: Manual
Video Signals: Composite video
Sensor Pixels Effective (H): 1945
Sensor Pixels Effective (V): 1097
Video Capture: 1920 x 1080 @ 60 fps
Sensor Pixels Total (H): 1945
Sensor Pixels Total (V): 1109
Digital Zoom: 24
Tilt: 0 to 59
Motion Detection: Yes
Panning Range (degree): 0 to 353
Angular Field of View (H, Min, Degree): 112
Angular Field of View (V, Min, Degree): 62
Min Focus Distance: 7.9 inch
Minimum Illumination: 0.0055 lux - B&W - F2.0 - shutter 1/30 sec, 0.055 lux - color - F2.0 - shutter 1/30 sec
Total Pixels: 2,000,000 pixels
Video Modes: 1080/60p, 720/60p
Image Sensor Size: 1/2.8"
Image Sensor Type: CMOS
Lens Aperture: F/2.0
Min Focal Length: 2.8 millimetre
Sensor Size (metric): 9.1 mm (1/2.8")
Digital Video Capture Resolution: 1024 x 768, 1280 x 1024, 1280 x 720, 1280 x 960, 1920 x 1080, 320 x 240, 640 x 360, 640 x 480, 720 x 480, 720 x 576, 800 x 448, 800 x 600
Max Frame Rate: 60 frames per second
Shutter Speed (Max): 1/12000 second (time unit)
Shutter Speed (Min): 2 second (time unit)
Focal Length Control: Fixed focal
Video Formats: AVC, H.264, H.265, MJPEG, MPEG-4
Video Input: Color
Touchscreen: No
Max Video Resolution: 1920 x 1080
Min Operating Temperature: -22 degree Fahrenheit
Max Operating Temperature: 131 degree Fahrenheit
Operating Humidity: 0 - 90%
Physical Characteristics
Indoor/Outdoor: Outdoor
Form Factor: Dome
Camera Mechanical Design: Fixed
Dimensions and Weight
Height: 2.5 inch
Width: 4.4 inch
Depth: 4.4 inch
Weight: 14.81 ounce
Not sure this camera fits your setup? Send us the model of your NVR, VMS or current cameras and how you plan to mount and power it, and the DatorPro team will help you confirm compatibility before you order.
