Product Information
The Hanwha WiseNet HRX-1635 is a 16 channel DVR with 16 BNC inputs for AHD, HD-TVI, HD-CVI and analog cameras, outputting up to 4K over HDMI and VGA. It has 4 audio inputs, 16 alarm inputs and 4 outputs, RS-422/485 PTZ control and fisheye dewarping in a metal housing. Black. No drive capacity listed.
Key Features
- 16 BNC inputs
- AHD, TVI, CVI
- 4K HDMI, VGA
- 16 alarm in, 4 out
- RS-422/485 PTZ
- No HDD listed
Product Information
Brand: Hanwha Techwin
Manufacturer: Hanwha
Product Line: Hanwha Vision WiseNet
Model: HRX-1635
Device Type: Standalone DVR
Packaged Quantity: 1
Color: Black
Color Category: Black
Network and Communication
DDNS Support: Yes
Network Interfaces: Ethernet 10Base-T/100Base-TX/1000Base-T
Supported Protocols: ARP, CGI, DDNS, DHCP, DNS, HTTP, HTTPS, ICMP, IGMP, NTP, PPPoE, RTP, RTSP, SMTP, SNMP, SSM, TCP/IP, UDP/IP, UPnP
Network Ports: 10/100/1000Base-T
Features #2: Analog High Definition (AHD), Fisheye Dewarp function, High Definition Composite Video Interface (HDCVI), High Definition Transport Video Interface (HDTVI), Metal housing, Mobile Viewer, Pan/Tilt/Zoom support, Recording data rate up to 128 Mbps, SmartViewer, Webviewer
Features: 802.1x authentication, Hanwha DDNS, IP address filtering, ONVIF Profile S, ONVIF support
Features: Analog High Definition (AHD), Fisheye Dewarp function, High Definition Composite Video Interface (HDCVI), High Definition Transport Video Interface (HDTVI), Metal housing, Mobile Viewer, Pan/Tilt/Zoom support, Recording data rate up to 128 Mbps, SmartViewer, Webviewer
Connectivity
Audio Inputs: RCA x 4
Additional Ports: USB 2.0, USB 3.0 x 1
Audio Outputs: RCA x 1
Video Output Ports: HDMI x 1, VGA x 1
Audio Channels: 4
Power
Input Voltage: 100 - 240 V
Frequency: 50/60 Hz
Technical Information
Alarm Ports: Alarm input x 16, Alarm output x 4
Camera Control Interface (PTZ): RS-422/485
TV System: NTSC/PAL
Compression Format: AVI, G.711, G.726, H.264, H.265, MJPEG
Video Input Ports: BNC x 16
Video Channels: 16
Image Resolution: 1024x768, 1280x1024, 1280x720, 1920x1080, 2560x1440, 3840x2160
Min Operating Temperature: 32 degree Fahrenheit
Max Operating Temperature: 104 degree Fahrenheit
Operating Humidity: 20 - 85% RH
Dimensions and Weight
Height: 3.5 inch
Width: 17.3 inch
Depth: 15.1 inch
Certifications and Listing
Compliant Standards: CE/EAC, cUL, FCC, IEEE 802.1x, KC, NDAA, Plug and Play, UKCA, UL
ENERGY STAR Certified: No
EPEAT Compliant: No
TCO Certified: No
