Product Information
This HID OMNIKEY 5022 uses USB-C with a 5 ft integrated cable and reads 13.56 MHz iCLASS, MIFARE Classic, Plus, Ultralight C and DESFire EV1/EV2/EV3 cards, plus FIDO2 NFC authenticators, with no drivers needed. It is USB powered in a dark blue polycarbonate housing and carries a 2 year limited warranty.
Key Features
- 13.56 MHz contactless
- iCLASS, MIFARE, DESFire EV1/EV2/EV3
- FIDO2 NFC authenticators
- USB-C, 5 ft integrated cable
- Driverless, USB powered
- 2 year limited warranty
Product Information
Brand: HID
Product Line: HID OMNIKEY
Model: 5022
Packaged Quantity: 1
Color: Dark blue
Color Category: Blue
Network and Communication
Operating System Required: Android 4.0, Apple MacOS X, Debian Linux 6.0 or later, Linux Fedora 15 or later, Microsoft Windows CE 6.0, Microsoft Windows CE 7.0, Microsoft Windows Server 2008 R2, Microsoft Windows Server 2012, Microsoft Windows Vista / 7 / 8 / 8.1 / 10 / 11, openSUSE 11.4 or later, Ubuntu 11.04 or later
Connectivity
Interface Type: USB-C
Input Adapter Type: SMART card reader
Interface Required Connections: 1 x USB - 24 pin USB-C
Power
Frequency: 13.56 MHz
Technical Information
Device Features: FIDO2 NFC authenticators support, iCLASS cards compatible, MiFare Classic EV1 cards compatible, MiFare DESFire cards compatible, MiFare DESFire EV1 cards compatible, MiFare DESFire EV2 cards compatible, MiFare DESFire EV3 cards compatible, MiFare Plus cards compatible, MiFare Ultralight C cards compatible, Polycarbonate housing, USB powered
OK Notification: LED indicator
SMART Card Reader Type: Contactless
TTL Decoding: Decoded
Audio Input Type: None
Touchscreen: No
Min Operating Temperature: 32 degree Fahrenheit
Max Operating Temperature: 158 degree Fahrenheit
Operating Humidity: 10 - 95% RH
MTBF: 500,000 hour(s)
Physical Characteristics
Form Factor (Input Device): External
Dimensions and Weight
Height: 0.4 inch
Width: 2.3 inch
Depth: 2.3 inch
Weight: 2.47 ounce
Included Items
Cables: 1 x USB-C cable - integrated - 5 ft
Certifications and Listing
Compliant Standards: FCC, ISO 14443 type A, ISO 14443 type B, ISO 15693, KCC, RCM, REACH, RoHS 2, UKCA, UL, WEEE
Warranty
Limited Warranty: 2 Year
Service & Support Details: Limited warranty - 2 years
