Product Information
Honeywell's Granit Ultra 2100iXR USB kit is a rugged, extended-range 2D handheld scanner for harsh environments, IP65/IP67 rated and MIL-STD 810G compliant, reading Data Matrix, DotCode, Digimarc and more.
Key Features:
- 2D imager; extended range
- USB 2.0 kit
- IP65/IP67; MIL-STD 810G
- Reads Data Matrix, DotCode, Digimarc, OCR
Specifications:
- Brand: Honeywell
- Manufacturer Part Number: 2100IXR-3USBN
- Standards & Compliance: IP65, IP67, MIL-STD 810G
- Interface Required: USB 2.0 Type A
- Barcode Symbology Supported: Code 128, Code 39, Data Matrix, Digimarc Barcode, DotCode, OCR, PDF417, Postal Code, QR code, UPC
- Sensor Resolution: 1280× 1080
- Electric Current Required: 175 mA (standby), 430 mA (operating)
- Power Consumption Operational: 2.15 watt
- Required Voltage: DC 4-5.5 volt
- Drop Specification: 10 ft
- Image Sensor Type: 2D imager
- Interface: USB 2.0
- Light Source: Green LED
- Max Operating Temperature: 122 degree Fahrenheit
- Min Operating Temperature: -22 degree Fahrenheit
- Minimum Bar Width: 5 milli-in
- Operating Humidity: 0-95% RH (non-condensing)
- Print Contrast Signal (PCS): 15%
- Skew (Degrees): 65
- Scanner Functionality: Barcode scanner
- Feature Set: 20 kV ESD protection (air discharge), 8 kV ESD protection (contact discharge), Rugged, Up to 100000 lux light levels
- Kit: USB Kit
- Max Coverage Angle: 65
- OK Notification: Beeper, LED indicator, Vibration
- TTL Decoding: Decoded
- Cables: 1× USB cable external 10 ft
- Listed Dimensions: Height 5.5 in, Width 3 in, Depth 7.7 in
- Weight: 11.64 oz
- Warranty: 3-year limited warranty
