Product Information
The HPE 462832-B21 is a Smart Array P411 SAS RAID controller with 512MB of Flash Backed Write Cache. It is an external connect only, low profile PCIe 2.0 card with 8 ports across two external SAS connectors, and it runs DDR2-800 cache memory.
Key Features
- 512MB FBWC protects cached writes without a battery
- RAID 0, 1, 1+0, 5 and 5+0 out of the box
- RAID 6 (ADG) and 6+0 available with the Smart Array Advanced Pack license key
- Cache can also be set up with a battery kit (BBWC) or FBWC, starting from a 512MB module
- 600 MB/s transfer rate per port
Condition: Refurbished (Grade A - Clean)
Warranty: 30 Days Warranty
Part Numbers
Manufacturer: HPE
Model: 462832-B21
MPN: 462832-B21
General
Product Type: Flash Backed Write Cache SAS Controller
Form Factor: Plug-in Card
Bracket Type: Low Profile
Designation: Select HPE ProLiant Servers
Supported Systems: HPE ProLiant and Smart Array Servers
Controller
Interface: PCI Express
Cache Size: 512 MB
Data Backup Type: Flash
Transfer Rate: 600 MB/s per port
RAID: Yes
Connections
External Connectors: 2 x SAS
Dimensions
Width x Depth x Height: 7.63 x 11 x 1.25
Compatible Systems
- HPE ProLiant DL and ML Series: DL1000, DL120 Gen6/Gen7, DL160 Gen6/Gen7, DL160se Gen6/Gen7, DL165 Gen6/Gen7, DL170h, DL180 Gen6/Gen7, DL320 Gen6/Gen7, DL360 Gen6/Gen7, DL365 Gen5, DL370 Gen6/Gen7, DL380 Gen6/Gen7, DL385 Gen5p, DL385 Gen6/Gen7, DL585 Gen5, DL585 Gen6/Gen7, DL785 Gen5, DL785 Gen6/Gen7, ML150 Gen6/Gen7, ML310 Gen5p, ML330 Gen6/Gen7, ML350 Gen6/Gen7, ML370 Gen6
Not sure this controller fits your system? Send us your server or storage model and the DatorPro team will confirm compatibility before you order.
