Product Information
HPE 507283-001 146GB Enterprise Hard Drive for ProLiant Generation4 to Generation7 Servers. This 2.5 inch Small Form Factor (SFF) drive spins at 10,000 RPM and connects through a dual port SAS 6Gbps interface.
Condition: Refurbished (Grade A - Clean)
Warranty: 30 Days Warranty
This drive is aimed at performance focused server storage. Spinning at 10,000 RPM, it answers requests quickly and holds up well under the constant, mixed read and write activity you see in databases, virtualization hosts and business applications.
SAS (Serial Attached SCSI) is the standard interface for server and storage drives. It supports hot swapping and full duplex data transfer, which is why it remains the common choice for systems that need to stay online.
Part Numbers
Brand: HPE
MPN: 507283-001
Option Part Number: 507125-B21
Spare Part Number: 507283-001
Model Number: DG0146FAMWL
Model Number: DG0146FARVU
Model Number: EG0146FARTR
Model Number: EG0146FAWHU
Model Number: EG0146FAWJC
Assembly Number: 507119-001
Assembly Number: 518194-001
Assembly Number: 518011-001
Assembly Number: 507119-003
Assembly Number: 518194-003
HPE GPN: 507129-001
Drive Details
Device Type: Hard Drive - Hot-Swap
Capacity: 146 GB
Interface: SAS 6Gbps
Form Factor: 2.5 inch SFF
Plug Type: Hot Plug
Byte per Sector: 512
Drive Technology (Fill): Air
Carrier Type: Standard Carrier
Features: Dual Port
Workload Type: Enterprise
Bundled with: HPE Standard Carrier
Platform Supported: HPE ProLiant Rack/Tower/BladeSystem Servers/Synergy
Speed and Throughput
Spindle Speed: 10000 RPM
External Data Transfer Rate: 6 Gb/sec
Average Seek Time: 4.00 ms
Max Seek Time: 7.48 ms
Track-to-Track Seek Time: 0.2 ms
Connection
Interfaces: 1 x SAS 6 Gb/s
Compatible Bays: 2.5" SFF
Operating Environment
Min Operating Temperature: 50 °F
Max Operating Temperature: 95 °F
Compatible Systems
HPE ProLiant BL Series: BL460c Gen6 (2.5inch), BL460c Gen7 (2.5inch), BL465c Gen5 (2.5inch), BL465c Gen6 (2.5inch), BL465c Gen7 (2.5inch), BL680c Gen5 (2.5inch), BL685c Gen5 (2.5inch), BL685c Gen6 (2.5inch), BL685c Gen7 (2.5inch)
HPE ProLiant DL Series: DL160 Gen6 (2.5inch), DL160se Gen6 (2.5inch), DL165 Gen7 (2.5inch), DL165 Gen7 Special Server (2.5inch), DL180 Gen6 Special Server (2.5inch), DL320 Gen6 (2.5inch), DL360 Gen5 (2.5inch), DL360 Gen5 High Efficiency (2.5inch), DL360 Gen6 (2.5inch), DL360 Gen6 Base (2.5inch), DL360 Gen6 Efficiency (2.5inch), DL360 Gen6 Entry (2.5inch), DL360 Gen6 Performance (2.5inch), DL360 Gen7 (2.5inch), DL360 Gen7 Base (2.5inch), DL360 Gen7 Entry (2.5inch), DL360 Gen7 Performance (2.5inch), DL365 Gen5 (2.5inch), DL365 Gen5 Base (2.5inch), DL365 Gen5 Entry (2.5inch), DL365 Gen5 High Efficiency (2.5inch), DL365 Gen5 Performance (2.5inch), DL370 Gen6 (2.5inch), DL370 Gen6 Base (2.5inch), DL370 Gen6 Performance (2.5inch), DL380 Gen5 High Efficiency (2.5inch), DL380 Gen6 (2.5inch), DL380 Gen6 Base (2.5inch), DL380 Gen6 Entry (2.5inch), DL380 Gen6 High Efficiency (2.5inch), DL380 Gen6 Performance (2.5inch), DL380 Gen6 Special Rack Server (2.5inch), DL380 Gen7 (2.5inch), DL380 Gen7 Base (2.5inch), DL380 Gen7 Entry (2.5inch), DL380 Gen7 Performance (2.5inch), DL385 Gen5 (2.5inch), DL385 Gen5 Base (2.5inch), DL385 Gen5 Entry (2.5inch), DL385 Gen5 Performance (2.5inch), DL385 Gen6 (2.5inch), DL385 Gen6 Base (2.5inch), DL385 Gen6 Entry (2.5inch), DL385 Gen6 High Performance (2.5inch), DL385 Gen6 ICE Performance (2.5inch), DL385 Gen7 (2.5inch), DL385 Gen7 Base (2.5inch), DL385 Gen7 Entry (2.5inch), DL385 Gen7 Performance (2.5inch), DL580 Gen5 (2.5inch), DL580 Gen5 Base (2.5inch), DL580 Gen5 High Performance (2.5inch), DL580 Gen5 Highly Serviceable Tower (2.5inch), DL580 Gen7 (2.5inch), DL580 Gen7 Base (2.5inch), DL580 Gen7 High Performance (2.5inch), DL585 Gen5 (2.5inch), DL585 Gen5 High Performance (2.5inch), DL585 Gen6 (2.5inch), DL585 Gen6 Base (2.5inch), DL585 Gen7 (2.5inch), DL585 Gen7 Base (2.5inch), DL585 Gen7 Performance (2.5inch), DL785 Gen6 (2.5inch), DL785 Gen6 Base (2.5inch), DL785 Gen6 Performance (2.5inch)
HPE ProLiant ML Series: ML110 Gen7 (2.5inch), ML350 Gen6 (2.5inch), ML350 Gen6 Base (2.5inch), ML350 Gen6 Performance (2.5inch), ML370 Gen5 High Performance (2.5inch), ML370 Gen6 (2.5inch), ML370 Gen6 Base (2.5inch), ML370 Gen6 Entry (2.5inch)
Not sure this drive fits your system? Send us your server or storage model and we will confirm compatibility before you order.
