Product Information
Add 450 GB of storage to HPE ProLiant Gen1 through Gen7 servers with the HPE 516810-001. This 3.5 inch LFF (large form factor) drive runs at 15,000 RPM over a dual port SAS 3Gb/s connection. The drive is hot swappable, so it can be installed or replaced while the system keeps running.
Use it where fast response matters: OLTP and other database workloads, large scale analytics, and HPC clusters.
Condition: Refurbished (Grade A - Clean)
Warranty: 30 Days Warranty
Part Numbers
Manufacturer: HPE
MPN: 516810-001
Option Part Number: 454232-B21
Spare Part Number: 454274-001
Model Number: EF0300FARMU
Assembly Number: 516810-001
Drive Details
Drive Type: Hard Drive - Internal
Storage Capacity: 450 GB
Host Interface: SAS 3Gbps
Form Factor: 3.5 inch LFF
Cache Buffer: 32 MB
Enclosure: Hot Swap
Ships With: HPE Standard Carrier
Performance
Rotational Speed: 15000 RPM
External Transfer Rate: 300 MBps
Drive Transfer Rate: 300 MBps (external)
Connections
Ports: 1 x SAS 3Gb/s
Fits Bay: 3.5" LFF
Compatible Systems
- HPE ProLiant DL Series: DL1000 DL120 (Gen5 Gen6 Gen7) DL140 (Gen3) DL145 (Gen3) DL160 (Gen5 Gen5p Gen6 Gen7) DL160se (Gen6 Gen7)DL165 (Gen5 Gen5p Gen6 Gen7) DL170e (Gen6) DL170h (Gen6) DL2x170h (Gen6) DL4x170h (Gen6)DL180 (Gen5 Gen6 Gen7) DL185 (Gen5) DL320 (Gen3 Gen4 Gen5 Gen5p Gen6 Gen7) DL320sDL370 (Gen6 Gen7)DL380 (Gen4 Gen5 Gen6 Gen7) DL385 (Gen5 Gen5p Gen6 Gen7) DL580 (Gen4 Gen5 Gen6 Gen7) DL585 (Gen2 Gen5 Gen6 Gen7)DL785 (Gen5 Gen6)
- HPE ProLiant ML Series: ML110 (Gen7) ML150 (Gen5 Gen6 Gen7) ML310 (Gen5p) ML330 (Gen6) ML350 (Gen5 Gen6 Gen7) ML370 (Gen5 Gen6 Gen7)
- HPE Storage Systems: D2600 MDS600 MSA60 P4300 P4500 P4000 (Gen2) 60 Modular Array StoreAll 9730
- HPE StorageEasy: 1430 1440 1530 1540 1630 1640 1830 1840 5530 X1400 X1500 X1600 X1800 X3400 X3800
Not sure this drive fits your system? Send us your server or storage model and the DatorPro team will confirm compatibility before you order.
