Product Information
The HPE 516814-B21 is a 300 GB enterprise class hard drive built for HPE ProLiant Gen2 through Gen7 servers and storage arrays. It spins at 15,000 RPM, uses the 3.5 inch LFF (large form factor) format and connects through a dual port SAS 6Gb/s interface.
Use it where fast response matters: OLTP and other database workloads, large scale analytics, and HPC clusters.
Condition: Refurbished (Grade A - Clean)
Warranty: 30 Days Warranty
Part Numbers
Manufacturer: HPE
MPN: 516814-B21
Option Part Number: 516814-B21
Spare Part Number: 517350-001
Model Number: EF0300FATFD, EF0300FARMU
Assembly Number: 533871-001, 516810-001
Drive Details
Drive Type: Hard Drive - Hot-Swap
Storage Capacity: 300 GB
Form Factor: 3.5 inch LFF
Host Interface: SAS-6Gbps
Enclosure: Hot Swap
Internal Fill: Air
Carrier: Standard Carrier
Workload Class: Enterprise
Ships With: HPE Standard Drive Carrier
Performance
Rotational Speed: 15000 RPM
External Transfer Rate: 600 MBps
Drive Transfer Rate: 600 MBps (external)
Connections
Ports: 1 x SAS 6 Gb/s
Fits Bay: 3.5" LFF
Operating Environment
Compliance: RoHS
Compatible Systems
- HPE ProLiant DL Series: DL1000 DL120 (Gen5 Gen6 Gen7) DL140 (Gen3) DL145 (Gen3) DL160 (Gen5 Gen5p Gen6 Gen7) DL160se (Gen6 Gen7) DL165 (Gen5 Gen5p Gen6 Gen7) DL170e (Gen6) DL170h (Gen6) DL2x170h (Gen6) DL4x170h (Gen6) DL180 (Gen5 Gen6 Gen7) DL185 (Gen5) DL320 (Gen3 Gen4 Gen5 Gen5p Gen6 Gen7) DL320sDL370 (Gen6 Gen7) DL380 (Gen4 Gen5 Gen6 Gen7) DL385 (Gen5 Gen5p Gen6 Gen7) DL580 (Gen4 Gen5 Gen6 Gen7) DL585 (Gen2 Gen5 Gen6 Gen7) DL785 (Gen5 Gen6)
- HPE ProLiant ML Series: ML110 (Gen7) ML150 (Gen5 Gen6 Gen7) ML310 (Gen5p) ML330 (Gen6) ML350 (Gen5 Gen6 Gen7) ML370 (Gen5 Gen6 Gen7)
- HPE Storage arrays: D2600 MDS600 MSA60 P4300 P4500 P4000 (Gen2) 60 Modular Array StoreAll 9730
- HPE StoreEasy: 1430 1440 1530 1540 1630 1640 1830 1840 5530 X1400 X1500 X1600 X1800 X3400 X3800
Not sure this drive fits your system? Send us your server or storage model and the DatorPro team will confirm compatibility before you order.
