Product Information
Add 450 GB of enterprise class storage to HPE ProLiant Gen5, Gen6 and Gen7 servers with the HPE 516832-004. This 3.5 inch LFF (large form factor) drive runs at 15,000 RPM over a dual port SAS 6Gb/s connection. The drive is hot swappable, so it can be installed or replaced while the system keeps running.
Use it where fast response matters: OLTP and other database workloads, large scale analytics, and HPC clusters.
Condition: Refurbished (Grade A - Clean)
Warranty: 30 Days Warranty
Part Numbers
Manufacturer: HPE
MPN: 516832-004
Option Part Number: 516816-B21
Spare Part Number: 517352-001
Model Number: EF0450FARMV, EF0450FATFE
Assembly Number: 516810-002, 533871-002
HPE GPN: 516832-004
Drive Details
Drive Type: Hard Drive - Hot-Swap
Storage Capacity: 450GB
Form Factor: 3.5 inch LFF
Host Interface: SAS 6Gbps
Cache Buffer: 16 MB
Sector Size (Bytes): 512
Installation Type: Hot Plug
Internal Fill: Air
Carrier: Standard Carrier
Workload Class: Enterprise
Features: Dual Port
Ships With: HPE Standard Carrier
Performance
Max Synchronous Transfer Rate: 6 Gb/sec
Single Track Seek (typical reads, incl. settling): 0.2 ms
Average Seek (typical reads, incl. settling): 3.5 ms
Full Stroke Seek (typical reads, incl. settling): 6.8 ms
Rotational Speed: 15000 RPM
Connections
Ports: 2 x SAS 6Gb/s
Fits Bay: 3.5" x 1/3H
Size and Weight
Height: 1.04 inch (26.4 mm)
Width: 4.36 inch (110.7 mm)
Depth: 7.43 inch (188.7 mm)
Weight: 1.60 lbs
Operating Environment
Operating Temp (Min): 50 °F
Operating Temp (Max): 95 °F
Compatible Systems
- HPE ProLiant DL Series: DL120 Gen7 (3.5 inch), DL120 Gen7 Base (3.5 inch), DL120 Gen7 Entry (3.5 inch), DL120 Gen7 Performance (3.5 inch), DL160 Gen5 (3.5 inch), DL160 Gen5 Special Server (3.5 inch), DL160 Gen5p (3.5 inch), DL160 Gen5p Special Server (3.5 inch), DL160 Gen6 (3.5 inch), DL160 Gen6 Special Server (3.5 inch), DL160se Gen6 (3.5 inch), DL165 Gen5 (3.5 inch), DL165 Gen5 Special Server (3.5 inch), DL165 Gen5p (3.5 inch), DL165 Gen5p Base (3.5 inch), DL165 Gen5p Performance (3.5 inch), DL165 Gen6 (3.5 inch), DL165 Gen7 (3.5 inch), DL165 Gen7 Base (3.5 inch), DL165 Gen7 Entry (3.5 inch), DL165 Gen7 Special Server (3.5 inch), DL180 Gen5 (3.5 inch), DL180 Gen5 Special Server (3.5 inch), DL180 Gen6 (3.5 inch), DL180 Gen6 Special Server (3.5 inch), DL185 Gen5 (3.5 inch), DL185 Gen5 Special Server (3.5 inch), DL2x170h Gen6 (3.5 inch), DL320 Gen6 (3.5 inch), DL320 Gen6 Entry (3.5 inch), DL320 Gen6 High Efficiency (3.5 inch), DL320 Gen6 Performance (3.5 inch), DL370 Gen6 (3.5 inch), DL370 Gen6 Special Server (3.5 inch), DL380 Gen6 (3.5 inch), DL380 Gen7 (3.5 inch), DL385 Gen5p (3.5 inch), DL385 Gen6 (3.5 inch), DL385 Gen6 Performance (3.5 inch), DL385 Gen7 (3.5 inch), DL4x170h Gen6 (3.5 inch) Servers
- HPE ProLiant ML Series: ML110 Gen7 (3.5 inch), ML150 Gen6 (3.5 inch), ML310 Gen5p (3.5 inch), ML330 Gen6 (3.5 inch), ML330 Gen6 Base (3.5 inch), ML350 Gen5 (3.5 inch), ML350 Gen5 Entry (3.5 inch), ML350 Gen6 (3.5 inch), ML350 Gen6 Entry (3.5 inch), ML350 Gen6 Performance (3.5 inch), ML350 Gen6 Special Server (3.5 inch), ML370 Gen6 (3.5 inch) Servers
Not sure this drive fits your system? Send us your server or storage model and the DatorPro team will confirm compatibility before you order.
