Product Information
Made for HPE ProLiant Gen2 through Gen7 servers, the HPE 517351-001 gives you 300 GB of enterprise class capacity in a 3.5 inch LFF (large form factor) package. It runs at 15,000 RPM and links to the controller over a dual port SAS 6Gb/s interface.
Use it where fast response matters: OLTP and other database workloads, large scale analytics, and HPC clusters.
Condition: New Bulk Pack
Warranty: 90 Days Warranty
Part Numbers
Manufacturer: HPE
MPN: 517351-001
Option Part Number: 516824-B21
Spare Part Number: 517351-001
Model Number: EF0300FATFD, EF0300FARMU
Assembly Number: 533871-001, 516810-001
HPE GPN: 516832-002
Drive Details
Drive Type: Internal Hard Drive
Storage Capacity: 300 GB
Host Interface: SAS-6Gbps
Form Factor: 3.5 inch LFF
Enclosure: Hot Swap
Internal Fill: Air
Carrier: Standard Carrier
Workload Class: Enterprise
Ships With: HPE Standard Drive Carrier
Performance
Rotational Speed: 15000 RPM
External Transfer Rate: 600 MBps
Drive Transfer Rate: 600 MBps (external)
Seek Time: 3.5 ms (average) / 6.8 ms (max)
Track-to-Track Seek: 0.2 ms
Connections
Ports: 1 x SAS 6 Gb/s
Fits Bay: 3.5" LFF
Size and Weight
Width: 4.60 inch
Depth: 7.40 inch
Height: 1.00 inch
Operating Environment
Operating Temp (Min): 50 °F
Operating Temp (Max): 95 °F
Compatible Systems
- HPE ProLiant DL Series: DL1000 DL140 Gen3 DL145 Gen3 DL160 Gen5 DL160 Gen5p DL160 Gen6 DL160se Gen6 DL165 Gen5 DL165 Gen5p DL165 Gen6 DL180 Gen1 DL180 Gen5 DL180 Gen6 DL185 Gen5 DL320 Gen3 DL320 Gen4 DL320 Gen5 DL320 Gen5p DL320 Gen6 DL320s DL370 Gen6 DL380 Gen6 DL385 Gen5p DL385 Gen6
- HPE ProLiant ML Series: ML150 Gen3 ML150 Gen5 ML150 Gen6 ML310 Gen2 ML310 Gen3 ML310 Gen4 ML310 Gen5 ML310 Gen5p ML330 Gen6 ML350 Gen5 ML350 Gen6 ML370 Gen6
Not sure this drive fits your system? Send us your server or storage model and the DatorPro team will confirm compatibility before you order.
