Product Information
Made for HPE ProLiant Gen1 through Gen7 servers, the HPE 517353-001 gives you 450 GB of enterprise class capacity in a 3.5 inch LFF (large form factor) package. It runs at 15,000 RPM and links to the controller over a dual port SAS 6Gb/s interface. The drive is hot swappable, so it can be installed or replaced while the system keeps running.
Use it where fast response matters: OLTP and other database workloads, large scale analytics, and HPC clusters.
Condition: Refurbished (Grade A - Clean)
Warranty: 30 Days Warranty
Part Numbers
Manufacturer: HPE
MPN: 517353-001
Option Part Number: 516826-B21
Spare Part Number: 517353-001
Model Number: EF0450FARMV, EF0450FATFE
Assembly Number: 516810-002, 533871-002
Drive Details
Drive Type: Hard Drive - Hot-Swap
Storage Capacity: 450GB
Form Factor: 3.5 inch LFF
Host Interface: SAS 6Gbps
Sector Size (Bytes): 512
Installation Type: Hot Plug
Internal Fill: Air
Carrier: Standard Carrier
Workload Class: Enterprise
Features: Dual Port
Ships With: HPE Standard Carrier
Performance
Drive Transfer Rate: 600 MBps (external)
Seek Time: 3.5 ms (average) / 6.8 ms (max)
Track-to-Track Seek: 0.2 ms
Rotational Speed: 15000 RPM
Connections
Ports: 1 x SAS 6Gb/s
Fits Bay: 3.5" LFF
Size and Weight
Width: 4.70 inch
Depth: 7.40 inch
Height: 1.00 inch
Operating Environment
Compliance: WEEE
Operating Temp (Min): 50 °F
Operating Temp (Max): 95 °F
Compatible Systems
- HPE ProLiant DL Series: DL120 Gen6, DL160 Gen6, DL320e (3.5 inch), DL320e (3.5 inch), DL320e Entry (3.5 inch), DL320e Performance (3.5 inch)
- HPE ProLiant ML Series: ML110 Gen6, ML110 Gen7, ML150 Gen6, ML310e (3.5 inch), ML310e (3.5 inch), ML310e (3.5 inch), ML310e(3.5 inch), ML310e, ML330 Gen6
Not sure this drive fits your system? Send us your server or storage model and the DatorPro team will confirm compatibility before you order.
