Product Information
The HPE 631667-B21 is a Smart Array P222 RAID controller with 512MB of flash backed write cache (FBWC). It is a low profile PCIe 3.0 x8 card for SAS and SATA drives, suited to HPE ProLiant servers.
Key Features
- RAID 0, 1, 5, 10 and 50
- Fits one PCIe 3.0 x8 slot
Condition: Refurbished (Grade A - Clean)
Warranty: 30 Days Warranty
Part Numbers
Manufacturer: HPE
MPN: 631667-B21
Option Part Number: 631667-B21
Spare Part Number: 633537-001
Assembly Number: 610669-003
General
Product Type: Storage controller (RAID) - plug-in card - low profile
Controller
Host Bus: PCIe 3.0 x8
Drive Interface: SATA 6Gb/s / SAS 6Gb/s
Transfer Rate: 600 MBps
Cache Size: 512 MB
Supported Devices: Hard drive, disk array (RAID)
Channels: 8
RAID Levels: RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, RAID 60, RAID 1 ADM, RAID 10 ADM
Connections
Ports: 1 x SATA 6Gb/s / SAS 6Gb/s - 36 pin 4i Mini MultiLane (internal) | 1 x SATA 6Gb/s / SAS 6Gb/s - 26 pin 4x Shielded Mini MultiLane SAS (SFF-8088) (external)
Slot: 1 x PCI Express 3.0 x8
In the Box: Full-height bracket
Software and Compatibility
Supported Operating Systems: SUSE Linux Enterprise Server, Microsoft Windows Server, Red Hat Enterprise Linux
Power and Environment
Compliance: WEEE
Compatible Systems
- HPE LTO-5 Ultrium 3000
- HPE ProLiant DL Series: DL160 Gen8, DL160 Gen8 Entry, DL160 Gen8 Performance, DL320e Gen8, DL320e Gen8 Base, DL320e Gen8 Entry, DL320e Gen8 Performance, DL360p Gen8, DL360p Gen8 Base, DL360p Gen8 CMS, DL360p Gen8 Entry, DL360p Gen8 High Performance, DL380e Gen8, DL380p Gen8, DL380p Gen8 Base, DL380p Gen8 Entry, DL380p Gen8 High Performance, DL380p Gen8 Special, DL385p Gen8, DL385p Gen8 Dedicated Workload, DL385p Gen8 Entry, DL385p Gen8 Maximized Consolidation, DL385p Gen8 Storage, DL560 Gen8, DL560 Gen8 Base, DL560 Gen8 Entry, DL560 Gen8 Performance
- HPE MicroServer Gen8, MicroServer Gen8 Base, MicroServer Gen8 Base Starter Kit, MicroServer Gen8 Entry, MicroServer Gen8 Performance
- HPE ProLiant ML Series: ML310e Gen8, ML310e Gen8 Base, ML310e Gen8 Entry, ML310e Gen8 Performance, ML310e Gen8 v2, ML310e Gen8 v2 Base, ML310e Gen8 v2 Entry, ML310e Gen8 v2 Performance, ML350e Gen8, ML350e Gen8 Base, ML350e Gen8 Entry, ML350e Gen8 Performance, ML350e Gen8 v2, ML350e Gen8 v2 Base
- HPE ProLiant SL Series: SL210t Gen8 1U Node, SL230s Gen8 1U Left Half Width Tray, SL230s Gen8 1U Right Half Width Tray, SL230s Gen8 Base 1U Left Tray Server, SL230s Gen8 Base 1U Right Tray Server, SL250s Gen8 2U Left Half Width Tray, SL250s Gen8 2U PCIe Gen3 Left Tray, SL250s Gen8 2U Right Half Width Tray, SL250s Gen8 Base 2U Left Half Width Tray, SL250s Gen8 Base 2U Right Half Width Tray, SL270s Gen8 1U Left Half Width Tray, SL270s Gen8 1U Right Half Width Tray, SL270s Gen8 Base 4U Left Half Width Tray, SL270s Gen8 Base 4U Right Half Width Tray, SL270s Gen8 SE 4U Left Tray, SL270s Gen8 SE 4U Right Tray
- HPE StorageWorks SAS Rack-Mount Kit
- HPE StoreEver 6250, LTO-6 Ultrium 6650
Not sure this controller fits your system? Send us your server or storage model and the DatorPro team will confirm compatibility before you order.
