Product Information
Made for HPE ProLiant Gen4 through Gen7 servers, the HPE 641552-001 gives you 300 GB of enterprise class capacity in a 2.5 inch SFF (small form factor) package. It runs at 10,000 RPM and links to the controller over a dual port SAS 6Gb/s interface. The drive is hot swappable, so it can be installed or replaced while the system keeps running.
Use it where fast response matters: OLTP and other database workloads, large scale analytics, and HPC clusters.
Condition: Refurbished (Grade A - Clean)
Warranty: 30 Days Warranty
Part Numbers
Manufacturer: HPE
MPN: 641552-001
Option Part Number: 507127-B21
Spare Part Number: 507284-001
Model Number: EG0300FBVFL
Assembly Number: 641552-001
HPE GPN: 507129-004
Drive Details
Drive Type: Hard Drive - Hot-Swap
Storage Capacity: 300 GB
Form Factor: 2.5 Inch SFF
Host Interface: SAS 6Gbps
Sector Size (Bytes): 512
Internal Fill: Air
Carrier: Standard Carrier
Workload Class: Enterprise
Installation Type: Hot Plug
Enclosure: Hot-Swap
Features: Dual Port
Ships With: HPE Standard Carrier
Performance
Drive Transfer Rate: 6 Gb/sec (external)
Rotational Speed: 10000 RPM
Average Seek: 4 ms
Maximum Seek: 7.45 ms
Track-to-Track Seek: 0.2 ms
Connections
Ports: 1 x SAS 6Gb/s
Fits Bay: 2.5" SFF
Size and Weight
Width: 3.11 inch (7.90 cm)
Height: 0.63 inch (1.60 cm)
Depth: 5.45 inch (13.80 cm)
Weight: 1.60 lbs
Operating Environment
Operating Temp (Max): 35 °C
Operating Temp (Min): 10 °C
Compatible Systems
- HPE Integrity BL Series: BL860c i2, BL870c i2, BL890c i2 Servers
- HPE ProLiant BL Series: BL460c Gen6, BL460c Gen7, BL465c Gen6, BL465c Gen7, BL620C Gen7, BL680c Gen7, BL685c Gen6, BL685c Gen7 Servers
- HPE ProLiant DL Series: DL160 Gen6, DL160se Gen6, DL165 Gen7, DL165 Gen7 Performance, DL180 Gen6, DL320 Gen6, DL360 Gen6, DL360 Gen6 Base, DL360 Gen6 Efficiency, DL360 Gen6 Entry, DL360 Gen6 Performance, DL360 Gen7, DL360 Gen7 Base, DL360 Gen7 Central Management Server, DL360 Gen7 Efficiency, DL360 Gen7 Entry, DL360 Gen7 Performance, DL370 Gen6, DL370 Gen6 Base, DL370 Gen6 High Performance, DL370 Gen6 Performance, DL380 Gen6, DL380 Gen6 Base, DL380 Gen6 Entry, DL380 Gen6 High Efficiency, DL380 Gen6 Performance, DL380 Gen7, DL380 Gen7 Base, DL380 Gen7 Efficiency, DL380 Gen7 Entry, DL380 Gen7 Performance, DL385 Gen6, DL385 Gen6 Base, DL385 Gen6 Entry, DL385 Gen6 High Performance, DL385 Gen7, DL385 Gen7 Base, DL385 Gen7 Entry, DL385 Gen7 HE, DL385 Gen7 Performance, DL580 Gen5 Highly Serviceable Tower, DL580 Gen7, DL580 Gen7 Base, DL580 Gen7 High Performance, DL585 Gen5 Performance, DL585 Gen6, DL585 Gen6 Base, DL585 Gen6 Performance, DL585 Gen7, DL585 Gen7 Base, DL585 Gen7 Performance, DL785 Gen6, DL785 Gen6 Base, DL785 Gen6 Performance, DL980 Gen7 Servers
- HPE ProLiant ML Series: ML110 Gen7, ML350 Gen6, ML350 Gen6 Base, ML350 Gen6 Performance, ML370 Gen6, ML370 Gen6 Base, ML370 Gen6 Entry Servers
- HPE ProLiant WS Series: WS460c Gen6 Workstation Blade
- HPE Modular Smart Array: P2000 Gen3 FC MSA Dual Controller Virtualization SAN Starter Kit
- HPE StorageWorks D2200sb PCIe Storage Blade
- HPE StorageWorks Disk Enclosure D2700
- HPE StorageWorks Modular Smart Array: 2324fc Gen2 Dual Controller, 2324sa Gen2 DL380 Gen6 Package Cluster, 2324sa Gen2 Dual Controller, 70 Dual Domain, P2000 2.5-in Drive Bay Chassis and P2000 Gen3 FC/iSCSI Dual Combo Controller SFF Array
- HPE StorageWorks Network Storage Blade X1800sb Gen2
- HPE StorageWorks Network Storage Gateway X3800sb Gen2
- HPE StorageWorks Network Storage System: X1600, X1600 292GB SAS Model, X1600 3TB SAS Model, X1600 5.4TB SAS Model, X1600 7.5TB SAS Model, X1600 Gen2, X1800, X1800 2.4TB SAS Model, X1800 292GB SAS Model, X1800 3.6TB SAS Model and X1800 Gen2
Not sure this drive fits your system? Send us your server or storage model and the DatorPro team will confirm compatibility before you order.
