Product Information
The HPE 656241-001 is a dual port 1Gb Ethernet low profile adapter on PCIe 2.0 x4 for select HPE ProLiant Gen8, Gen9 and Gen10 ML, DL and SL servers. It runs at full line rate on both ports while keeping power use low.
Key Features
- Intel I350 controller
- Suits virtualization, security, consolidation and network segmentation
- Large send and receive offload, VLAN tagging, jumbo frames, MSI-X, and TCP checksum and segmentation offload
- Precision Time Protocol (IEEE 1588 PTP)
- VMware NetQueue and Microsoft VMQ
- HPE Sea of Sensors 3D Technology helps cut energy use
Condition: Refurbished (Grade A - Clean)
Warranty: 30 Days Warranty
Part Numbers
Manufacturer: HPE
MPN: 656241-001
Option Part Number: 652497-B21
Spare Part Number: 656241-001
General
Product Type: Network adapter
Form Factor: Plug-in card-low profile
Adapter Details
Bus Type: PCI Express 2.0 x4
PCI Spec Revision: PCIe 2.0
Connectivity: Wired
Data Link Protocol: 10Mb LAN, 100Mb LAN, GigE
Transfer Rate: 1 Gbps
Remote Management: SNMP
Status Indicators: Link activity, port transmission speed
Features: Auto-negotiation, wake on LAN (WOL), network fault tolerance (NFT), Jumbo Frames support, PXE support, Large Send Offload (LSO), Energy Efficient Ethernet
Processor: 1 x I350-Intel
Connections
Ports: Gigabit Ethernet x 2, 2 x 1000Base-T - RJ-45
Cabling: Ethernet 10Base-T, Ethernet 100Base-TX, Ethernet 1000Base-T
Slot: 1 x PCI Express 2.0 x4 - low-profile
In the Box: Low-profile bracket
Software and Compatibility
Supported Operating Systems: SuSE Linux Enterprise Server, Microsoft Windows Server 2008, Microsoft Windows HPC Server 2008, Oracle Solaris 10, Red Hat Enterprise Linux 6.1, VMware ESX 4.1, VMware ESXi 4.1, VMware ESXi 5, Red Hat Enterprise Linux 5.7, Citrix XenServer 6.0
Size and Weight
Depth: 5.30 inch
Height: 2.50 inch
Power and Environment
Compliance: IEEE 802.3, IEEE 802.3u, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1as, IEEE 802.3az, FCC Class B certified, UL, VCCI Class B ITE, CISPR 22 Class B, DOC-B, EN 60950, UL 1950, VCCI-II, WHQL, EN55022 Class B, ICES-003 Class B, MIC Class B, WEEE, RoHS, BSMI Class A
Operating Temp (Min): 32 °F
Operating Temp (Max): 131 °F
Operating Humidity: 10 - 90% (non-condensing)
Compatible Systems
- HPE ProLiant DL Series: DL165 Gen7 DL580 Gen7 DL585 Gen7 DL980 Gen7 DL160 Gen8 Gen9 (Gen8 Gen9) DL320e Gen8 Gen9 (Gen8 Gen9) DL360 Gen10 (Gen10) DL360e Gen8 Gen9 (Gen8 Gen9) DL360p Gen8 Gen9 (Gen8 Gen9) DL380 Gen10 (Gen10) DL380e Gen8 Gen9 (Gen8 Gen9) DL380p Gen8 Gen9 (Gen8 Gen9) DL385 Gen10 (Gen10) DL385p Gen8 Gen9 (Gen8 Gen9) DL560 Gen8 Gen9 (Gen8 Gen9) DL560 Gen10 (Gen10) DL580 Gen10 (Gen10)
- HPE ProLiant ML Series: ML110 Gen10 (Gen10) ML310e Gen8 Gen9 (Gen8 Gen9) ML350 Gen10 (Gen10) ML350e Gen8 Gen9 (Gen8 Gen9) ML350p Gen8 Gen9 (Gen8 Gen9)
- HPE ProLiant SL Series: SL230s Gen8 Gen9 (Gen8 Gen9) SL250s Gen8 Gen9 (Gen8 Gen9) SL270s Gen8 Gen9 (Gen8 Gen9)
Not sure this adapter fits your system? Send us your server or storage model and the DatorPro team will confirm compatibility before you order.
