Product Information
The HPE 695503-004 gives you 4TB of storage in a midline hard drive running at 7,200 RPM. It is a 3.5 inch large form factor (LFF), hot swap drive with a 3Gb SATA interface, for HPE ProLiant Gen1 through Gen7 servers.
Key Features
- 4TB capacity at 7.2K RPM
- SATA 3Gb/s interface
- 3.5 inch LFF
- Hot swap
- Midline class
Condition: Refurbished (Grade A - Clean)
Warranty: 30 Days Warranty
Specifications
Brand: HPE
MPN: 695503-004
Option Part Number: 694374-B21
Spare Part Number: 694534-001
Model Number: MB4000GCWDC
Assembly Number: 695503-004
General
Device Type: Hard Drive - Hot-Swap
Capacity: 4 TB
Form Factor: 3.5 inch LFF
Interface: SATA 3Gbps
Bytes per Sector: 512
Features: Native Command Queuing (NCQ)
Spindle Speed: 72000 RPM
External Data Transfer Rate: 300 MBps
Enclosure: Hot Swap
Drive Technology (Fill): Air
Carrier Type: Standard Carrier
Workload: Midline
Bundled with: HPE Standard Drive Carrier
Performance
Drive Transfer Rate: 300 MBps (external)
Seek Time: 8.5 ms (average) / 16.2 ms (max)
Track-to-Track Seek Time: 0.8 ms
Spindle Speed: 7200 RPM
Expansion & Connectivity
Interfaces: 1 x SATA 3 Gb/s
Compatible Bays: 3.5" LFF
Dimensions and Weight
Width: 4.40 inch
Depth: 7.30 inch
Height: 1.00 inch
Environmental Parameters
Min Operating Temperature: 50 °F
Max Operating Temperature: 95 °F
Compatible Systems
- HPE ProLiant DL Series: DL1000 DL120 (Gen5 Gen6 Gen7) DL140 (Gen3) DL145 (Gen3) DL160 (Gen5 Gen5p Gen6 Gen7) DL160se (Gen6 Gen7) DL165 (Gen5 Gen5p Gen6 Gen7) DL170e (Gen6) DL170h (Gen6) DL2x170h (Gen6) DL4x170h (Gen6) DL180 (Gen5 Gen6 Gen7) DL185 (Gen5) DL320 (Gen3 Gen4 Gen5 Gen5p Gen6 Gen7) DL320sDL370 (Gen6 Gen7) DL380 (Gen4 Gen5 Gen6 Gen7) DL385 (Gen5 Gen5p Gen6 Gen7) DL580 (Gen4 Gen5 Gen6 Gen7) DL585 (Gen2 Gen5 Gen6 Gen7) DL785 (Gen5 Gen6)
- HPE ProLiant ML Series: ML110 (Gen7) ML150 (Gen5 Gen6 Gen7) ML310 (Gen5p) ML330 (Gen6) ML350 (Gen5 Gen6 Gen7) ML370 (Gen5 Gen6 Gen7)
- HPE Storage arrays: D2600 MDS600 MSA60 P4300 P4500 P4000 (Gen2) 60 Modular Array StoreAll 9730
- HPE StoreEasy: 1430 1440 1530 1540 1630 1640 1830 1840 5530 X1400 X1500 X1600 X1800 X3400 X3800
Not sure this drive fits your system? Send us your server or storage model and the DatorPro team will confirm compatibility before you order.
