Product Information
HPE 695507-007 3TB Midline Hard Drive for ProLiant Generation2 to Generation7 Servers. This 3.5 inch Large Form Factor (LFF) drive spins at 7,200 RPM and connects through a dual port SAS 6Gbps interface.
Condition: Refurbished (Grade A - Clean)
Warranty: 30 Days Warranty
When the goal is storing a lot of data at a sensible cost, a midline drive is the practical choice. This 7,200 RPM drive suits backup targets, file servers, archive tiers and other capacity driven storage where every drive slot counts.
SAS (Serial Attached SCSI) is the standard interface for server and storage drives. It supports hot swapping and full duplex data transfer, which is why it remains the common choice for systems that need to stay online.
Part Numbers
Brand: HPE
MPN: 695507-007
Option Part Number: 625031-B21
Spare Part Number: 625140-001
Model Number: MB3000FCWDH
Assembly Number: 695507-007
Drive Details
Device Type: Hard Drive - Hot-Swap
Capacity: 3 TB
Form Factor: 3.5 inch LFF
Interface: SAS 6Gbps
Bytes per Sector: 512
Drive Technology (Fill): Air
Connectivity: Dual Port
Plug Type: Hot Pluggable
Carrier Type: Standard Carrier (ST)
Workload Type: Midline
Bundled with: HPE Standard Carrier (ST)
Speed and Throughput
Drive Transfer Rate (External): 6 Gb/sec
Drive Rotational Speed: 7200 rpm
Connection
Interfaces: 1 x SAS - 29 pin internal SAS (SFF-8482)
Compatible Bay: 3.5" LFF
Size
Width: 4.60 inch
Depth: 7.40 inch
Height: 1.00 inch
Compatible Systems
HPE Modular Disk System 600
HPE ProLiant DL Series: DL160 Gen6 (3.5 inch), DL160 Gen6 Special Server (3.5 inch), DL165 Gen7 Base (3.5 inch), DL180 Gen6 (3.5 inch), DL180 Gen6 Special Server (3.5 inch), DL320 Gen6 (3.5 inch), DL320 Gen6 Entry, DL320 Gen6 High Efficiency, DL320 Gen6 Performance, DL370 Gen6 Special Server (3.5 inch), DL380 Gen7 (3.5 inch)
HPE ProLiant ML Series: ML150 Gen6
HPE StorageWorks Disk Enclosure D2600
HPE StorageWorks Modular Disk System 600, 600 with two Dual Port I/O Module System
HPE StorageWorks Network Storage System X1400 G2, X1500 G2, X1600 Gen2 (3.5 inch LFF)
HPE StoreAll 9730 Storage Couplet
HPE StoreEasy 12 LFF Disk Enclosure
Not sure this drive fits your system? Send us your server or storage model and we will confirm compatibility before you order.
