Product Information
The HPE 781514-004 is a 900GB, 10,000 RPM enterprise hard drive. It uses the 2.5 inch small form factor (SFF) with a dual port 12Gb SAS interface.
Key Features
- 900GB capacity at 10K RPM
- Dual port SAS 12Gb/s interface
- 2.5 inch SFF
- Enterprise class
Condition: Brand New in Factory Sealed Box
Warranty: Up to a 3-Years Manufacturer Warranty and a 30 Days Return Window through us
Specifications
Brand: HPE
MPN: 781514-004
Option Part Number: 785075-B21
Spare Part Number: 785414-001
Model Number: EG0900JFCKB
Assembly Number: 781514-004
General
Device Type: Hard Drive - Hot-Swap
Capacity: 900 GB
Form Factor: 2.5 inch SFF
Interface: SAS 12 Gbps
Bytes per Sector: 512
Drive Technology (Fill): Air
Plug Type: Hot Pluggable
Format Type: 512e
Carrier Type: Standard Carrier (SC)
Workload Type: Enterprise
Bundled with: HPE Standard Carrier
Platform Supported: HPE ProLiant Rack/Tower/BladeSystem Servers/Synergy
Expansion & Connectivity
Interfaces: 1 x SAS 12 Gb/s
Compatible Bays: 2.5" SFF
Performance
Drive Transfer Rate: 1.2 GBps (external)
Seek Time: 3.5 ms (average) / 7 ms (max)
Track-to-Track Seek Time: 0.1 ms
Spindle Speed: 10000 RPM
Environmental Parameters
Min Operating Temperature: 50 °F
Max Operating Temperature: 95 °F
Product Dimensions
Height: 0.63 inch (16.00 cm)
Width: 3.10 inch (78.70 cm)
Depth: 5.45 inch (138.40 cm)
Compatible Systems
- HPE Integrity BL Series: BL860c i4 (2.5 inch), BL860c i4 Base (2.5 inch)
- HPE ProLiant BL Series: BL20p Gen4 (2.5 inch), BL45p Gen2 (2.5 inch), BL460c Gen6 Gen7 (2.5 inch), BL465c Gen1 Gen5 Gen6 Gen7 (2.5 inch), BL480c Gen7 (2.5 inch), BL620c Gen7 (2.5 inch), BL680c Gen5 Gen6 Gen7 (2.5 inch), BL685c Gen6 Gen7 (2.5 inch)
- HPE ProLiant DL Series: DL120 Gen6 Gen7 (2.5 inch), DL160 Gen6 Gen7 (2.5 inch), DL160se Gen6 Gen7 (2.5 inch), DL165 Gen6 Gen7 (2.5 inch), DL170e Gen6 Gen7 (2.5 inch), DL170h Gen6 Gen7 (2.5 inch), DL180 Gen6 Gen7 (2.5 inch), DL320 Gen6 Gen7 (2.5 inch), DL360 Gen4p Gen5 Gen6 Gen7 (2.5 inch), DL365 Gen1 Gen5 Gen6 Gen7 (2.5 inch), DL370 Gen6 Gen7 (2.5 inch), DL380 Gen4 Gen5 Gen6 Gen7 (2.5 inch), DL385 Gen1 Gen2 Gen3 Gen4 Gen5/Gen5p Gen6 Gen7 (2.5 inch), DL580 Gen3 Gen4 Gen5 Gen6 Gen7 (2.5 inch), DL580 Gen7 Base (2.5 inch), DL580 Gen7 High Performance (2.5 inch), DL585 Gen2 Gen3 Gen4 Gen6 Gen7 (2.5 inch), DL585 Gen7 Base (2.5 inch), DL585 Gen7 Performance (2.5 inch), DL785 Gen6 (2.5 inch), DL980 Gen7 (2.5 inch)
- HPE ProLiant ML Series: ML110 Gen7 (2.5 inch), ML350 Gen5 Gen6 Gen7 (2.5 inch), ML370 Gen5 Gen6 Gen7 (2.5 inch), ML570 Gen3 Gen4 Gen5 (2.5 inch)
- HPE ProLiant SL Series: SL390s Gen6 Gen7 (2.5 inch)
- HPE ProLiant WS Series: WS460c Gen6 Gen7 (2.5 inch)
- HPE Storage arrays: D2700 SFF, MSA 1040 SFF, MSA70 SFF, P2000 Gen3 SFF, X1500 Gen2 SFF, X16000 Gen2 SFF, X1800 Gen2 SFF, X3400 Gen2 SFF, X3800 Gen2 SFF, 2000i Gen2 SFF, 2000sa Gen2 SFF
Not sure this drive fits your system? Send us your server or storage array model and the DatorPro team will confirm compatibility before you order.
