Product Information
The HPE 790316-001 is the Ethernet 10Gb 2-port 562SFP+ adapter, a low cost, low power PCIe 3.0 x8 card for HPE ProLiant Gen9 and Gen10 servers. Two SFP+ cages accept DAC cables or SR fiber optic modules.
Key Features
- Intel X710 controller
- Low profile and standard brackets are both in the box
- SR-IOV lets several VMs share the adapter without losing runtime speed
- Per VM offloads cut I/O bottlenecks for near native performance
- VXLAN and NVGRE stateless offloads spread overlay traffic across CPU cores
- DPDK for efficient packet processing, strong small packet speed for appliances and NFV
- VLAN tagging, low latency interrupts, TCP/UDP checksum offload, MSI-X, NIC teaming, RSS, jumbo frames and PXE boot
- Wake on LAN support, and near line rate throughput of 40Gb/s in both directions combined
- Part of HPE's extended catalog, so new stock often has a longer lead time
Also Supported
Checksum and segmentation offload, OS specific configuration utilities, DPDK, HPE Sea of Sensors 3D, IPv6, Jumbo Frames, LED status indicators, SNMP management support, MSI-X, NIC teaming, VMware NetQueue and Microsoft VMQ virtualization support, PXE boot, RSS, TCP/UDP/IP checksum offloads, Precision Time Protocol (IEEE 1588 PTP)
Condition: New Bulk Pack
Warranty: 90 Days Warranty
Part Numbers
Manufacturer: HPE
MPN: 790316-001
Option Part Number: 727055-B21
Spare Part Number: 790316-001
General
Product Type: Network adapter
Form Factor: Standard and low profile adapter compliant with the PCIe standard
Adapter Details
Bus Type: PCI Express 3.0 at 8 GT/s x8
Network Processor: Intel® X710 Controller
Connectivity: Wired
Data Link Protocol: 10 GigE
Data Rate: Two ports, each at 20 Gb/s bi-directional; 40 Gb/s aggregate bi-directional theoretical bandwidth.
Jumbo Frame Size: 9.5 KB
Status Indicators: Status, link/activity
Features: Wake on LAN (WOL), PXE support
IEEE Standards: 802.3, 802.1ab, 802.3x, 802.3ad, 802.3p, 802.1q, 802.3ae, 802.1au, 802.3ap, 802.1as, 802.3ak,802.1qaz, 802.1Qbb
Processor: 1 (Intel® X710 Controller)
Onboard Memory: 256 MB
Connections
Ports: 10 Gigabit SFP+ x 2, 2 x 10Gb Ethernet - SFP+
Software and Compatibility
Supported Operating Systems: SuSE Linux Enterprise Server 11, Microsoft Windows Server 2008 R2, SuSE Linux Enterprise Server 10, Microsoft Windows Server 2008, Microsoft Windows HPC Server 2008, Red Hat Enterprise Linux 6, Red Hat Enterprise Linux 5.x, Oracle Solaris 10, VMware ESX 4.1, VMware ESXi 4.1, Microsoft Windows Server 2012
Certifications and Approvals
Emissions Class: Class B
RoHS Compliance: 5 of 6
Safety Standards: UL Mark (USA and Canada), CE Mark, EN 605901 2nd edition
USA: FCC Part 15 Class B
Canada: ICES-003, Issue 5
Japan: VCCI 2011-04 Class B
International: EN55022:2010 + Class B, EN55024:2010, EN61000-3-2:2006, EN61000-3-3:2008
Taiwan: BSMI, CNS13438 (2006) Class B
Australia/New Zealand (AS/NZS): AS/NZS CISPR 22: 2009+A1:2010 Class
Korea: KN22 Class B, KN24
Power and Environment
Power Draw (typical): 10.00 Watt
Power Draw (max): 10.80 Watt
Operating Temp (Min): 32 °F (0 °C)
Operating Temp (Max): 131 °F (55 °C)
Operating Humidity: 5 - 95% (non-condensing)
Compatible Systems
- HPE ProLiant DL Series: DL20 Gen10, DL20 Gen10 Entry, DL20 Gen10 Performance, DL20 Gen10 solution, DL60 Gen9, DL80 Gen9, DL80 Gen9 Entry, DL120 Gen9, DL160 Gen9, DL180 Gen9, DL180 Gen9 Base, DL180 Gen9 Entry, DL180 Gen9 Storage, DL360 Gen9, DL360 Gen10, DL360 Gen10 Base, DL360 Gen10 Entry, DL360 Gen10 High Performance, DL360 Gen10 Low, DL360 Gen10 Performance, DL360 Gen10 Solution, DL380 Gen9, DL380 Gen10, DL380 Gen10 Base, DL380 Gen10 Entry, DL380 Gen10 High Performance, DL380 Gen10 Performance, DL380 Gen10 Solution, DL385 Gen10, DL560 Gen9, DL560 Gen10, DL560 Gen10 Base, DL560 Gen10 Entry, DL560 Gen10 Performance, DL580 Gen9, DL580 Gen10, DL580 Gen10 Base, DL580 Gen10 Entry, DL580 Gen10 Performance Servers
- HPE ProLiant ML Series: ML30 Gen10, ML30 Gen10 Entry, ML30 Gen10 Performance, ML30 Gen10 Solution, ML110 Gen9, ML110 Gen9 Base, ML110 Gen9 Entry, ML110 Gen10, ML110 Gen10 Performance, ML110 Gen10 Solution, ML150 Gen9, ML350 Gen9, ML350 Gen10, ML350 Gen10 Base, ML350 Gen10 Entry, ML350 Gen10 Performance, ML350 Gen10 Solution, ML350 Gen10 Sub-Entry Servers
- HPE ProLiant XL Series: XL230a Gen9 NHP Compute Tray (12G), XL230k Gen10 Compute Tray, XL270d Gen9, XL450 Gen10 Servers
- HPE Apollo 2000 Series: XL170r Gen9, 2000 XL190r Gen9 Servers
- HPE Apollo 4200 Gen9 Server
- HPE Apollo 4500 XL450 Gen9 Server
- HPE Apollo 6000 Series: XL230a Gen9, XL250a Gen9, XL260a Gen9, XL270d Gen9 Servers
- HPE Apollo 6500 XL270d Gen10 Server
- HPE StoreEasy: 1450, 1850, 3850 Gateway Single Node
Not sure this adapter fits your system? Send us your server or storage model and the DatorPro team will confirm compatibility before you order.
