Product Information
The HPE 804394-B21 is a Smart Array E208i-p SR plug-in controller for HPE ProLiant Gen10 servers. It installs in a PCIe slot and runs 12Gb/s SAS RAID.
Key Features
- Enterprise-class RAID performance and data protection for ProLiant Gen10 rack and tower servers
- Internal storage can be scaled further with an optional SAS Expander Card
Condition: Refurbished (Grade A - Clean)
Warranty: 30 Days Warranty
Part Numbers
Manufacturer: HPE
MPN: 804394-B21
Option Part Number: 804394-B21
Spare Part Number: 836266-001
General
Product Type: Storage Controller (RAID) - Plug-in Card
Controller
Host Bus: PCI Express 3.0 x8
Drive Interface: SATA 6Gb/s / SAS 12Gb/s
Transfer Rate: 12 Gbit/s
Supported Devices: Hard drive, disk array (RAID)
Channels: 8
RAID Levels: RAID 0, RAID 1, RAID 5, RAID 10
Max LUNs: 64
Connections
Ports: 2 x SATA 6Gb/s / SAS 12Gb/s (internal)
Software and Compatibility
Supported Operating Systems: Microsoft Windows Server, Red Hat Enterprise Linux, CentOS, Oracle Solaris, Citrix XenServer, Oracle Linux, ClearOS, VMware vSphere (ESXi), Microsoft Windows Hyper-V Server
Compatible Systems
- HPE Apollo 4200 Gen10, 4200 Gen10 384TB 25Gb Capacity Server for Cohesity DataPlatform, 4200 Gen10 384TB Capacity Server for Cohesity DataPlatform, 4200 Gen10 for
- HPE Ezmeral Container Platform, 4510 Gen10
- HPE Nimble Storage dHCI Large Solution with
- HPE ProLiant DL380 Gen10, Medium Solution with
- HPE ProLiant DL360 Gen10, Small Solution with
- HPE ProLiant DL360 Gen10
- HPE ProLiant DL Series: DL160 Gen10, DL160 Gen10 Base, DL160 Gen10 Entry, DL160 Gen10 SMB, DL180 Gen10 Entry, DL325 Gen10 Base, DL325 Gen10 Plus V2 Base, DL325 Gen10 Solution, DL345 Gen10 Plus Base, DL360 Gen10 All Flash Server for Weka, DL360 Gen10 Compute Server for Cohesity DataPlatform, DL360 Gen10 Low, DL360 Gen10 Network Choice, DL360 Gen10 Performance for Cohesity DataPlatform, DL360 Gen10 Plus, DL360 Gen10 Plus Network Choice, DL360 Gen10 SMB, DL360 Gen10 SMB Network Choice, DL360 Gen10 Solution, DL365 Gen10 Plus, DL380 Gen10 48TB Server for Cohesity DataPlatform, DL380 Gen10 96TB Server for Cohesity DataPlatform, DL380 Gen10 All Flash Server for Datera, DL380 Gen10 Entry SMB, DL380 Gen10 for Cohesity DataPlatform, DL380 Gen10 for SAP HANA Compute Block, DL380 Gen10 High Performance, DL380 Gen10 Hybrid Server for Datera, DL380 Gen10 Network Choice, DL380 Gen10 Network Choice for CTERA, DL380 Gen10 NVMe All Flash Server for Datera, DL380 Gen10 Plus Network Choice, DL380 Gen10 Server for CTERA, DL380 Gen10 SMB, DL380 Gen10 SMB Networking Choice, DL380 Gen10 Solution, DL388 Gen10 Network Choice, DL560 Gen10 for SAP HANA Compute Block
- HPE MicroServer Gen10 Plus Entry, MicroServer Gen10 Plus Performance, MicroServer Gen10 Plus SMB, MicroServer Gen10 Solution
- HPE ProLiant XL Series: XL170r Gen10, XL170r Gen10 24TB Server for Cohesity DataPlatform, XL170r Gen10 36TB Add-on Server for Cohesity DataPlatform, XL170r Gen10 Server for BlueData EPIC, XL190r Gen10, XL190r Gen10 for
- HPE Ezmeral Container Platform, XL225n Gen10 Plus 1U Node, XL230k Gen10 Compute Tray, XL645d Gen10 Plus
Not sure this controller fits your system? Send us your server or storage model and the DatorPro team will confirm compatibility before you order.
