Product Information
The HPE 826074-B21 is a 4TB midline hard drive that spins at 7,200 RPM. It uses the 3.5 inch large form factor (LFF) with a dual port 12Gb SAS interface.
Key Features
- 4TB capacity at 7.2K RPM
- Dual port SAS 12Gb/s interface
- 3.5 inch LFF
- Midline class
Condition: Refurbished (Grade A - Clean)
Warranty: 30 Days Warranty
Specifications
Brand: HPE
MPN: 826074-B21
Option Part Number: 826074-B21
Spare Part Number: 826550-001
Model Number: MB4000JVYZQ
Model Number: MB4000JFDSN
Model Number: MB4000JFEPB
Assembly Number: 846523-004
Assembly Number: 818364-002
Assembly Number: 820409-002
HPE GPN: 818369-004
General
Device Type: Hard Drive - Hot-Swap
Capacity: 4 TB
Interface: SAS 12 Gbps
Form Factor: 3.5 inch LFF
Bytes per Sector: 512
Drive Technology (Fill): Air
Connectivity: Dual Port
Plug Type: Hot Pluggable
Carrier Type: Standard Carrier
Workload Type: Midline
Bundled with: HPE Standard Carrier
Performance
Drive Transfer Rate: 12 Gb/sec (external)
Internal Data Rate: 215 MBps
Average Latency: 4.16 ms
Spindle Speed: 7200 RPM
Expansion & Connectivity
Interfaces: 2 x SAS 12 Gb/s
Compatible Bay: 3.5" LFF Power Consumption Idle Time: 6.52 Watts
Active Time: 7.74 Watts
Environmental Parameters
Min Operating Temperature: 41 °F
Max Operating Temperature: 140 °F
Compatible Systems
- HPE ProLiant DL Series: DL120 (Gen5 Gen6 Gen7), DL140 (Gen3), DL145 (Gen3), DL160 (Gen5 Gen5p Gen6 Gen7), DL160se (Gen6 Gen7), DL165 (Gen5 Gen5p Gen6 Gen7), DL170e (Gen6), DL170h (Gen6), DL2x170h (Gen6), DL4x170h (Gen6), DL180 (Gen5 Gen6 Gen7), DL185 (Gen5), DL320 (Gen3 Gen4 Gen5 Gen5p Gen6 Gen7), DL320sDL370 (Gen6 Gen7), DL380 (Gen4 Gen5 Gen6 Gen7), DL385 (Gen5 Gen5p Gen6 Gen7), DL580 (Gen4 Gen5 Gen6 Gen7), DL585 (Gen2 Gen5 Gen6 Gen7), DL785 (Gen5 Gen6)
- HPE ProLiant ML Series: ML110 (Gen7), ML150 (Gen5 Gen6 Gen7), ML310 (Gen5p), ML330 (Gen6), ML350 (Gen5 Gen6 Gen7), ML370 (Gen5 Gen6 Gen7)
- HPE Storage Arrays: D2600 MDS600 MSA60 60 Modular Array StoreAll 9730
- HPE StoreEasy: 1430 1440 1530 1540 1630 1640 1830 1840 5530 X1400 X1500 X1600 X1800 X3400 X3800
- HPE StoreVirtual: P4000 P4100 P4300 (Gen2), P4500 (Gen2)
Not sure this drive fits your system? Send us your server or storage array model and the DatorPro team will confirm compatibility before you order.
