Product Information
The HPE 861680-002 is a 2TB midline hard drive that spins at 7,200 RPM. It uses the 3.5 inch large form factor (LFF) with a 6Gb SATA interface. The drive comes with HPE digitally signed firmware and a low profile carrier. It is intended for HPE ProLiant Gen8, Gen9 and Gen10 servers.
Key Features
- 2TB capacity at 7.2K RPM
- SATA 6Gb/s interface
- 3.5 inch LFF
- Digitally signed firmware
- Low Profile carrier
- Midline class
Condition: New Bulk Pack
Warranty: 90 Days Warranty
Specifications
Brand: HPE
MPN: 861680-002
Option Part Number: 861681-B21
Spare Part Number: 862132-001
Model Number: MB002000GWFGH
Assembly Number: 871332-002
HPE GPN: 861680-002
General
Device Type: Hard Drive - Hot-Swap
Capacity: 2 TB
Form Factor: 3.5 inch LFF
Interface: SATA 6Gbps
Bytes per Sector: 512
Plug Type: Hot Pluggable
Format Type: 512n
Carrier Type: Low Profile Carrier (LPC)
Workload: Midline
Features: Advanced Format 512n, Digitally Signed Firmware (DS)
Bundled with: HPE Low Profile Carrier (LPC)
Platform Supported: HPE ProLiant Rack/Tower/BladeSystem Servers/Synergy
Performance
Rotational Speed: 7200 RPM
Drive Transfer Rate: 6 Gb/sec (external)
Single Track Seek Time: 0.32 ms
Average Seek Time: 7.45 ms
Full Stroke Seek Time: 14.2 ms
OD Media Rate, Max Sequential Throughput (MiB/s): 195
128Kib Random Rd (IOPs): 90
128Kib Random 70% RD/ 30% WT (IOPs): 90
128Kib Random 50% RD/ 50% WT (IOPs): 90
Expansion & Connectivity
Interfaces: 1 x SAS 6 Gb/s
Compatible Bay: 3.5 inch LFF
Environmental Parameters
Min Operating Temperature: 50 °F (10°C)
Max Operating Temperature: 95 °F (35°C) Power Consumption Idle Time: 2.60 Watt
Sequential Read: 4.40 Watt
Sequential Write: 3.90 Watt
Random Read/Write: 3.60 Watt
Product Dimensions
Height: 1.028 inch (26.10 mm)
Width: 4.15 inch (105.50 mm)
Depth: 6.16 inch (156.58 mm)
Compatible Systems
- HPE Apollo Series: 4200 Gen9 (3.5 inch), 4200 Gen9 for Google (3.5 inch), 4510 Gen9 (3.5 inch), 4520 Gen9 (3.5 inch), 4530 (3.5 inch)
- HPE ProLiant DL Series: DL180 Gen10 (3.5 inch), DL180 Gen10 Entry (3.5 inch), DL180 Gen10 SMB (3.5 inch), DL20 Gen10 (3.5 inch), DL20 Gen10 Entry (3.5 inch), DL20 Gen10 Performance (3.5 inch), DL20 Gen10 solution (3.5 inch), DL325 Gen10 Base (3.5 inch), DL325 Gen10 Plus (3.5 inch), DL325 Gen10 Solution (3.5 inch), DL385 Gen10 Plus (3.5 inch), DL385 Gen10 Plus Entry (3.5 inch)
- HPE ProLiant ML Series: ML110 Gen10 (3.5 inch), ML110 Gen10 Entry (3.5 inch), ML110 Gen10 Performance (3.5 inch), ML110 Gen10 Solution (3.5 inch), ML30 Gen10 (3.5 inch), ML30 Gen10 Entry (3.5 inch), ML30 Gen10 Performance (3.5 inch), ML30 Gen10 Solution (3.5 inch), ML350 Gen10 (3.5 inch), ML350 Gen10 Base (3.5 inch), ML350 Gen10 Entry (3.5 inch), ML350 Gen10 High Performance (3.5 inch), ML350 Gen10 Performance (3.5 inch), ML350 Gen10 SMB (3.5 inch), ML350 Gen10 Solution (3.5 inch), ML350 Gen10 Special Server (3.5 inch), ML350 Gen10 Sub-Entry (3.5 inch)
Not sure this drive fits your system? Send us your server or storage array model and the DatorPro team will confirm compatibility before you order.
