Product Information
The HPE Aruba AP-503R (R8N05A#ABA) is a desktop Wi-Fi 6 remote access point for home workers and small branches, running AOS 10. It has 2x2:2 MIMO up to 1.49 Gbps, two Gigabit ports, USB and Bluetooth 5.0, and comes with an AC power adapter.
Key Features
- Wi-Fi 6 dual band, 2x2:2
- Up to 1.49 Gbps
- 2 x Gigabit RJ-45, USB 2.0
- Bluetooth 5.0
- AOS 10 remote AP
- AC power adapter included
Product Information
Brand: HPE
Manufacturer: Aruba
Product Line: HPE Aruba Networking
Model: AP-503R-US
Product Type: Wireless access point
Packaged Quantity: 1
Color Category: White
Country: United States
Localization: English
Network and Communication
Connectivity Technology: Wireless
Data Link Protocols: Bluetooth 5.0, IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax (Wi-Fi 6), IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Encryption: Opportunistic Wireless Encryption (OWE), Simultaneous Authentication of Equals (SAE), WPA, WPA2, WPA3-Enterprise
Data Transfer Rate: 1.49 GBps
Line Coding Format: 1024 QAM, 16 QAM, 256 QAM, 64 QAM, BPSK, CCK, QPSK
Capacity: BSSIDs per radio: 16, OFDMA units: 8, Wireless clients per Wi-Fi radio: 256
Wireless LAN: 802.11a/b/g/n/ac/ax, Bluetooth 5.0
Network Band: 2.4 GHz, 5 GHz
Spread Spectrum Method: DSSS, OFDM, OFDMA
Network Device: Maximum data rate (2.4 GHz): 574 Mbps, Maximum data rate (5 GHz): 1.2 Gbps
Antennas: 2
Antenna Form Factor: Internal
Directivity: Omni-directional
Operating System Required: ArubaOS 10.5.0.0, InstantOS 10.5.0.0
Features: 2x2 MIMO technology, 2x2:2 streams, Advanced Cellular Coexistence (ACC), Cyclic Delay Diversity (CDD), Cyclic shift diversity (CSD), DFS support, High Efficiency (HE) support, High-Throughput (HT) support, Low Density Parity Check (LDPC), Maximum Ratio Combining (MRC), Packet aggregation A-MPDU, Packet aggregation A-MSDU, Security slot (Kensington security lock compatible), Space Time Blocking Code (STBC), Target Wait Time (TWT), Transmit Beam-forming (TxBF) ready, Trusted Platform Module (TPM), Very High Throughput (VHT) support, Wi-Fi Multimedia (WMM) support
Connectivity
Interface Provided: 1 x console - micro-USB, 1 x USB 2.0 - Type A, 2 x 10/100/1000Base-T - RJ-45
Technical Information
Min Operating Temperature: 32 degree Fahrenheit
Max Operating Temperature: 104 degree Fahrenheit
Operating Humidity: 5 - 95% RH
MTBF: 71 Year
Ruggedized Design: Indoor
Physical Characteristics
Form Factor: Desktop
Status Indicators: Power, Status, System
Dimensions and Weight
Height: 1.5 inch
Width: 5.9 inch
Depth: 5.9 inch
Weight: 11.29 ounce
Included Items
Included Accessories: AC power adapter & plug
Certifications and Listing
Compliant Standards: EMC 2014/30/EU, EN 60601-1-1, EN 60601-1-2, ETS 300 019 Class 1.2, ETS 300 019 Class 2.3, ETS 300 019 Class 3.2, FCC, IEC/EN 62368-1, IEC/EN/UL 60950, ISED, LVD 2014/35/EU, RED 2014/53/EU
Compliant Standards: IEEE 802.11b, IEEE 802.3az, Wi-Fi CERTIFIED 6
ENERGY STAR Certified: No
EPEAT Compliant: No
TCO Certified: No
Warranty
Limited Warranty: Limited Lifetime
Service & Support Details: Limited warranty - lifetime
Service Activation: No
