Product Information
The HPE Aruba AP-635 (R7J27A) is the rest of world version of the 630 series campus Wi-Fi 6E access point, with three 2x2:2 radios across 2.4, 5 and 6 GHz. The spec lists 2.4 Gbps while the description quotes 3.9 Gbps aggregate. It adds Bluetooth 5.0 and Zigbee and two multi-gig ports.
Key Features
- Wi-Fi 6E tri-band: 2.4, 5, 6 GHz
- 2x2:2 MU-MIMO on each band
- 2.5G RJ-45 + Smart Rate RJ-45
- Bluetooth 5.0 and Zigbee
- RW (rest of world) version
- Mounting bracket included
Product Information
Brand: Aruba
Manufacturer: Aruba
Product Line: HPE Aruba
Model: AP-635 (RW)
Product Type: Wireless access point
Packaged Quantity: 1
Color Category: White
Network and Communication
Connectivity Technology: Wireless
Data Link Protocols: Bluetooth 5.0, IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax (Wi-Fi 6E), IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, ZigBee
Encryption: CNSA, Opportunistic Wireless Encryption (OWE), WPA, WPA-Enterprise, WPA-Personal, WPA2-MPSK, WPA3
Data Transfer Rate: 2.4 GBps
Line Coding Format: 1024 QAM, 16 QAM, 256 QAM, 4096 QAM, 64 QAM, BPSK, CCK, OFDM, OFDMA, QPSK
Capacity: BSSIDs per radio: 16, OFDMA units: 8, Wireless clients per Wi-Fi radio: 512
Wireless LAN: 802.11a/b/g/n/ac/ax (Wi-Fi 6E), Bluetooth 5.0, ZigBee
Network Band: 2.4 GHz, 5 GHz, 6 GHz
Spread Spectrum Method: DSSS, OFDM, OFDMA
Network Device: Aggregate bandwidth: 3.9 Gbps, Maximum data rate (2.4 GHz): 287 Mbps, Maximum data rate (5 GHz): 1.2 Gbps, Maximum data rate (6 GHz): 2.4 Gbps
IoT Communications Technology: Bluetooth Low Energy (LE), Zigbee
Internet of Things (IoT) Compatible: Yes
Antenna Form Factor: Internal
Antenna Gain Level: 7 DBi
Directivity: Omni-directional
Operating System Required: ArubaOS, InstantOS
Features: 2x2:2 MU-MIMO technology, Advanced Cellular Coexistence (ACC), Aruba AirMatch, Auto-uplink (auto MDI/MDI-X), ClientMatch, Custom deep-sleep mode, Cyclic Delay Diversity (CDD), Cyclic shift diversity (CSD), Direct Sequence Spread Spectrum (DSSS), Dynamic Frequency Selection (DFS), Energy-Efficient Ethernet (EEE), High Efficiency (HE) support, High-Throughput (HT) support, Intelligent Power Monitoring (IPM), LED off mode, Low Density Parity Check (LDPC), Maximum Ratio Combining (MRC), Orthogonal Frequency Division Multiple Access (OFDMA), Orthogonal Frequency Division Multiplexing (OFDM), Packet aggregation A-MPDU, Packet aggregation A-MSDU, Security slot (Kensington security lock compatible), Space Time Blocking Code (STBC), Target Wait Time (TWT), Transmit Beam-forming (TxBF) ready, Trusted Platform Module (TPM), Unified AP support, Very High Throughput (VHT) support, Wi-Fi 6E technology, Wi-Fi Multimedia (WMM) support, WMM Power Save
Edition: Campus
Connectivity
Interface Provided: 1 x 2.5 GBase-T - RJ-45, 1 x console - micro-USB, 1 x HPE Smart Rate - RJ-45, 1 x USB 2.0 - Type A
Power Over Ethernet (PoE): PoE
Power
Power Consumption Operational: 26.4 watt
Memory and Processor
Optical Drive Type: None
Technical Information
Min Operating Temperature: 32 degree Fahrenheit
Max Operating Temperature: 122 degree Fahrenheit
Operating Humidity: 5 - 95% (non-condensing)
MTBF: 59 Year
Ruggedized Design: Indoor
Physical Characteristics
Form Factor: External
Status Indicators: Status, System
Dimensions and Weight
Height: 2 inch
Width: 8.7 inch
Depth: 8.7 inch
Weight: 2.87 lbs
Included Items
Included Accessories: Mounting bracket
Certifications and Listing
Compliant Standards: IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3bz, Wi-Fi CERTIFIED 6
Compliant Standards: EMC 2014/30/EU, EN 60601-1-1, EN 60601-1-2, EN 60950, EN 62368-1, FCC, IEC 60950, IEC 62368-1, ISED, LVD 2014/35/EU, RED 2014/53/EU, UL 2043, UL 60950
ENERGY STAR Certified: No
EPEAT Compliant: No
TCO Certified: No
Warranty
Service Activation: No
