Product Information
The HPE Aruba Networking CX 6300M (S5Z46A) is a stackable Layer 3 switch with 24 SFP+ ports at 1/10G and four SFP56 ports at 50G for uplinks or stacking. It supports EVPN, PTP and ERPS, offers 880 Gbps of switching capacity and stacks up to 10 units. One hot-plug power supply is installed.
Key Features
- 24 x 1/10G SFP+ ports
- 4 x 50G SFP56 ports (uplink or stacking)
- 880 Gbps switching, 654 Mpps
- Layer 3, EVPN, PTP, ERPS
- Stacks up to 10 units
- 1 hot-plug power supply installed, front-to-back airflow
Product Information
Brand: Aruba
Manufacturer: Aruba
Product Line: HPE Aruba Networking CX
Model: 6300M 24p SFP+ 1G/10G 4p SFP56 50G
Product Type: Switch
Subcategory: Network hubs and switches
Packaged Quantity: 1
Color Category: Black, Silver
Country: United States
Localization: English
Network and Communication
Advanced Switching: Layer 3
Switching Type: 10 Gigabit Ethernet
Manageable: Yes
Remote Management: CLI, RMON, SNMP, SNMP 2c, SNMP 3
Routing Protocol: BGP, BGP-4, ECMP, IGMP, MP-BGP, OSPF, OSPFv2, PIM-SM, VRF, VXLAN
Authentication Method: RADIUS, Secure Shell (SSH), Secure Shell v.2 (SSH2), TACACS+
Performance: Latency (1 Gbps): 1.99 µs, Latency (10 Gbps): 1.49 µs, Latency (25 Gbps): 2.85 µs, Latency (50 Gbps): 2.82 µs, Switching capacity: 880 Gbps, Throughput: 654 Mpps
Jumbo Frame Support: 9198 bytes
Stackable: Stackable
Features: Ethernet Ring Protection Switching (ERPS), Ethernet Virtual Private Network (EVPN), Precision Time Protocol (PTP), Quality of Service (QoS), Rapid Per-VLAN Spanning Tree Plus (PVRST+), Top-of-Rack (ToR), Unsupported Transceiver Mode (UTM), Virtual Stacking Framework (VSF)
Features: Port-to-power airflow
Max Units In A Stack: 10
Connectivity
Ports: 24
Port Quantity: 24
Port Type: 1 Gigabit / 10 Gigabit SFP+
Ports (2nd) Quantity: 4
Ports Type (2nd): 50 Gigabit Ethernet SFP56
Interface Provided: 1 x management RJ-45 out-of-band network management, 1 x USB Type A AUX, 1 x USB-C console, 24 x 1/10Gbit LAN SFP+, 4 x 50Gbit LAN SFP56 uplink/stacking
Power
Device Type: Internal power supply
Required Voltage: AC 100-240 volt
Power Provided: 250 watt
Power Supplies Installed: 1
Power Supplies Supported: 2
Redundant Power Supply Supported: N+1 (with optional power supply), N+N (with optional power supply)
Redundant Power Supply: Optional
Hot-Plug: Hot-plug
Memory and Processor
Processor Brand: ARM
Processor Number: Cortex-A72
Processors Installed: 1
Clock Speed: 1.8 GHZ
RAM Installed: 8 GB
Memory Technology: DDR4 SDRAM
Flash Memory Installed: 32 GB
Physical Characteristics
Form Factor (Hubs & Switches): Rack-mountable
Height (Rack Units): 1
Airflow Direction: Front to back airflow
Dimensions and Weight
Height: 1.7 inch
Width: 17.4 inch
Depth: 15.2 inch
Included Items
Included Accessories: 2 port-to-power fan trays
Certifications and Listing
Compliant Standards: IEEE 802.1ab (LLDP), IEEE 802.1ak, IEEE 802.1AX, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1t, IEEE 802.1v, IEEE 802.1w, IEEE 802.3ad (LACP), IEEE 802.3ae, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3bt, IEEE 802.3bz, IEEE 802.3x, IEEE 802.3z
ENERGY STAR Certified: No
EPEAT Compliant: No
TCO Certified: No
