Product Information
HPE's Aruba Networking 8320 (JL579A) is a 1U Layer 3 switch with 32 40G QSFP+ ports and a switching capacity of 2.5 Tbps. This bundle includes five X472 fans and two hot-plug power supplies, supports VSX and MLAG, and is TAA compliant.
Key Features
- 32 x 40G QSFP+ ports
- 2.5 Tbps switching capacity
- VSX, MLAG, Layer 3
- 5 x X472 fans included
- 2 hot-plug power supplies, 1+1
- TAA compliant
Product Information
Brand: Aruba
Manufacturer: Aruba Data Center Switches
Product Line: HPE Aruba
Model: 8320
Product Type: Switch
Subcategory: Network hubs and switches
Packaged Quantity: 1
Color Category: Black
Country: United States
Localization: English
Network and Communication
Advanced Switching: Layer 3
Switching Type: 40 Gigabit Ethernet
Manageable: Yes
Remote Management: CLI, RMON, SFTP, SNMP, SNMP 2c, SNMP 3, SSH, TFTP
Routing Protocol: ECMP, GRE, IGMP, IGMPv2, IGMPv3, OSPF, Static IPv6 routing, VRRP
Authentication Method: RADIUS, Secure Shell v.2 (SSH2), TACACS+
Encryption: FIPS 140-2
Performance: Forwarding performance: 1.905 Mpps, Switching capacity: 2.5 Tbps
Capacity: Virtual interfaces (VLANs) per port for 802.1q: 4096
MAC Address Table Size: 14K entries
Jumbo Frame Support: 9KB
Features: Access Control List (ACL) support, Bridge protocol data unit (BPDU), IPv4 support, IPv6 support, Link Aggregation Control Protocol (LACP), Loopback, Multi-Chassis Link Aggregation (MLAG), Multiple Spanning Tree Protocol (MSTP) support, Packet storm protection, Protocol Independent Multicast (PIM), Quality of Service (QoS), Rapid Per-VLAN Spanning Tree Plus (PVRST+), Rapid Spanning Tree Protocol (RSTP) support, Redundant hot swappable fans, sFlow, Spanning Tree Protocol (STP) support, Strict Priority (SP), Uni-Directional Link Detection (UDLD), VPN support
Connectivity
Ports: 32
Port Quantity: 32
Port Type: 40 Gigabit QSFP+
Interface Provided: 1 x console (micro-USB), 1 x RJ-45, 1 x serial RJ-45, 32 x 40Gbit LAN QSFP+
Power
Device Type: Internal power supply
Frequency: 50/65 hertz
Power Consumption Operational: 310 watt
Power Provided: 400 watt
Power Supplies Installed: 2
Power Supplies Supported: 2
Redundant Power Supply Supported: 1+1
Redundant Power Supply: Yes
Hot-Plug: Hot-plug
Memory and Processor
Processors Installed: 1
Clock Speed: 2 GHZ
RAM Installed: 16 GB
Flash Memory Installed: 8 megabyte
Technical Information
Min Operating Temperature: 32 degree Fahrenheit
Max Operating Temperature: 104 degree Fahrenheit
Operating Humidity: 5 - 95% (non-condensing)
Min Storage Temperature: -40 degree Fahrenheit
Max Storage Temperature: 158 degree Fahrenheit
Humidity Range Storage: 5 - 95% (non-condensing)
MTBF: 296526 Hours
Physical Characteristics
Form Factor (Hubs & Switches): Rack-mountable
Height (Rack Units): 1
Rack Mounting Kit: Included
Dimensions and Weight
Height: 1.7 inch
Width: 17.2 inch
Depth: 20.3 inch
Weight: 21.38 lbs
Included Items
Bundled With: X472 5 Fans 2 Power Supply
Certifications and Listing
Compliant Standards: IEEE 802.1ab (LLDP), IEEE 802.1ad, IEEE 802.1ae, IEEE 802.1ak, IEEE 802.1AX, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1t, IEEE 802.1w, IEEE 802.3ad (LACP), IEEE 802.3ae, IEEE 802.3ba, IEEE 802.3x, IEEE 802.3z
Compliant Standards: AS/NZS, CISPR 24, CISPR 32 Class A, CISPR 32:2015 Class A, CNS 13438, CSA 22.2 No. 60950-1, Directive 2014/35/EU, EN 50581:2012, EN 55024:2010, EN 55032:2015, EN 60825-1:2007, EN 60950-1:2006+A11:2009+A1:2010+A12:2011+A2:2013, EN 61000-3-2, EN 61000-3-3, EN 61000-4-11, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, FCC CFR47 Part 15 A, ICES-003 issue 5, IEC 60825-1:2007 Class 1, IEC 60950-1:2005 (ed.2)+A1:2009+A2:2013, IEC 61000-3-2, IEC 61000-3-3, IEC 61000-4-8, RoHS, UL 60950-1, WEEE
ENERGY STAR Certified: No
EPEAT Compliant: No
TCO Certified: No
TAA Compliant: Yes
