Product Information
HPE's S0U63A is a line module for the Aruba Networking CX 5420 chassis, with 20 Gigabit Class 4 PoE ports and four 1/10G SFP+ ports that also support LRM optics. It installs in a CX 5420 chassis and is not a standalone switch.
Key Features
- 20 x 10/100/1000 RJ-45 Class 4 PoE ports
- 4 x 1/10G SFP+ ports, LRM support
- Plug-in module for CX 5420 chassis
- Layer 3, front to back airflow
Product Information
Brand: HPE
Manufacturer: Aruba
Product Line: HPE Aruba Networking CX
Model: 5420 20p 10M/100M/1G Class4 PoE 4p SFP+ 1G/10G LRM Module
Product Type: Switch
Subcategory: Network hubs and switches
Packaged Quantity: 1
Color Category: Black, Silver
Network and Communication
Advanced Switching: Layer 3
Switching Type: Gigabit Ethernet
Manageable: Yes
Remote Management: CLI, NTP, RMON, SFTP, SNMP 2c, SNMP 3, SSH, TFTP
Routing Protocol: ECMP, IGMP, IGMPv3, MLDv2, MSTP, OSPF, RSTP, Static IP routing, Static IPv6 routing, STP, VRRP
Authentication Method: RADIUS, Secure Shell (SSH), TACACS+
Features: Bridge protocol data unit (BPDU), Egress Queue Shaping (EQS), Layer 2 switching, Layer 3 routing, Link Aggregation Control Protocol (LACP), LRM optics support, Multiple VLAN Registration Protocol (MVRP), Quality of Service (QoS), Rapid Per-VLAN Spanning Tree Plus (PVRST+), REST API interface, sFlow, Type of Service (ToS), Uni-Directional Link Detection (UDLD), Virtual Route Redundancy Protocol (VRRP) support
Connectivity
Ports: 20
Port Quantity: 20
Port Type: 10/100/1000 (PoE Class 4)
Ports (2nd) Quantity: 4
Ports Type (2nd): 1 Gigabit / 10 Gigabit SFP+
Interface Provided: 20 x 10/100/1000 Base-T RJ-45 PoE Class 4, 4 x 1/10GBase-LRM SFP+
Power Over Ethernet (PoE): PoE Class 4
Technical Information
Min Operating Temperature: 32 degree Fahrenheit
Max Operating Temperature: 113 degree Fahrenheit
Operating Humidity: 5 - 95% RH (non-condensing)
Min Storage Temperature: -40 degree Fahrenheit
Max Storage Temperature: 158 degree Fahrenheit
Humidity Range Storage: 5 - 95% RH (non-condensing)
Physical Characteristics
Form Factor (Hubs & Switches): Plug-in module
Height (Rack Units): 1
Airflow Direction: Front to back airflow
Dimensions and Weight
Height: 1.7 inch
Width: 8.4 inch
Depth: 9 inch
Weight: 29.92 ounce
Certifications and Listing
Compliant Standards: IEEE 802.1ab (LLDP), IEEE 802.1ak, IEEE 802.1AX, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1t, IEEE 802.1v, IEEE 802.1w, IEEE 802.3ab, IEEE 802.3ad (LACP), IEEE 802.3ae, IEEE 802.3af, IEEE 802.3az, IEEE 802.3z
Compliant Standards: CAN/CSA C22.2 No. 62368-1-19, CISPR 32:2015+AMD1:2019 Class A, CISPR 35: 2016, CNS 15598-1:2020, Directive 2014/35/EU, EN 55032:2015+A11:2020 Class A, EN 55035:2017+A11:2020, EN 60825-1:2014 + A11:2021, EN 62368-1:2014+A11:2017 2nd Ed., EN IEC 61000-3-2, EN IEC 62368-1:2020+A11:2020 Third Edition, FCC Part 15 B Class A, IEC 60825-1:2014, IEC 61000-4-11, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, IEC 62368-1: 2014 Second Edition, IEC 62368-1:2018 Third Edition, IEC/EN 61000-3-3, Laser Class 1, UL 62368-1 Third Edition, VCCI
ENERGY STAR Certified: No
EPEAT Compliant: No
TCO Certified: No
Warranty
Limited Warranty: Limited Lifetime
Service & Support Details: Limited warranty - lifetime
