Product Information
This HPE Broadcom BCM57504 adapter (P26269-B21) is a quad port SFP28 card in the OCP 3.0 form factor for HPE Gen10 Plus servers. Each port runs at 10 or 25 Gb Ethernet, with RoCE v2, SR-IOV, NPAR, DPDK and tunnel offloads for NVGRE and GENEVE. Security features include firmware root of trust, secure boot and sanitization, and it draws about 16 W.
Key Features
- Broadcom BCM57504 controller
- 4 x 10/25GbE SFP28 ports
- OCP 3.0 form factor
- RoCE v2 and SR-IOV
- Firmware root of trust
- For HPE Gen10 Plus servers
Product Information
Brand: Broadcom
Manufacturer: Hewlett-Packard
Product Line: Broadcom
Model: BCM57504
Product Type: Network adapter
Packaged Quantity: 1
Color Category: Black, Green, Silver
Network and Communication
Connectivity Technology: Wired
Data Link Protocols: 10 Gigabit Ethernet, 25 Gigabit Ethernet, RDMA over Converged Ethernet (RoCE v2)
Data Transfer Rate: 25 GBps
Features: Audit logs, Data Plane Development Kit (DPDK), Firmware root of trust, GENEVE support, IPv4 support, IPv6 support, Legacy BIOS PXE Boot, Mware NetQueue and Microsoft Virtual Machine Queue (VMQ), Network Partitioning (NPAR), Network Virtualization using Generic Routing Encapsulation (NVGRE), Open Compute Project (OCP) 3.0 support, Receive Side Scaling (RSS), Sanitization, Secure Boot, Single Root I/O Virtualization (SR-IOV), UEFI PXE Boot, UEFI support, Virtual Extensible LAN (VXLAN), Wake On LAN (WOL)
Connectivity
PCI Specification Revision: PCIe 4.0
Port Quantity: 4
Interface Provided: 4 x 10Gb Ethernet/25Gb Ethernet - SFP28
Network & Adapter Ports: 10Gb Ethernet / 25Gb Ethernet SFP28
Host Interface: Open Compute Project mezzanine (OCP) 3.0
Power
Power Consumption Operational: 16 watt
Memory and Processor
Processor Brand: Broadcom
Processor Number: BCM57504
Processors Installed: 1
Physical Characteristics
Form Factor: Plug-In Card
Certifications and Listing
ENERGY STAR Certified: No
EPEAT Compliant: No
TCO Certified: No
Warranty
Limited Warranty: 1 Year
Service & Support Details: Limited warranty - 1 year
