Product Information
The HPE P26871-001 is a Broadcom based dual port 10/25Gb Ethernet adapter with SFP28 ports and a PCIe 3.0 x8 interface, made for HPE ProLiant Gen10 Plus servers.
Key Features
- Broadcom BCM57414 controller
- Up to 25Gbps per port
Condition: Brand New in Factory Sealed Box
Warranty: Up to a 3-Years Manufacturer Warranty and a 30 Days Return Window through us
Part Numbers
Manufacturer: HPE
MPN: P26871-001
Option Part Number: P26262-B21
Spare Part Number: P26871-001
General
Product Type: Network Adapter
Form Factor: Plug-in Card
Adapter Details
Bus Type: PCI Express 3.0 x8
PCI Spec Revision: PCIe 3.0
Connectivity: Wired
Data Link Protocol: Gigabit Ethernet, 10 Gigabit Ethernet, 25 Gigabit Ethernet, RDMA over Converged Ethernet (RoCE v1), RDMA over Converged Ethernet (RoCE v2)
Transfer Rate: 25 Gbps
Features: IPv6 support, IPv4 support, Receive Side Scaling (RSS), UEFI support, Single Root I/O Virtualization (SR-IOV), Virtual Extensible LAN (VXLAN), Network Virtualization using Generic Routing Encapsulation (NVGRE), secure boot, Network Partitioning (NPAR), Mware NetQueue and Microsoft Virtual Machine Queue (VMQ), Data Plane Development Kit (DPDK), firmware root of trust, audit logs, tunnel offload, GENEVE support, sanitization, UEFI PXE Boot, legacy BIOS PXE Boot
Processor: 1 x Broadcom BCM57414
Connections
Network Ports: Gigabit Ethernet / 10Gb Ethernet / 25Gb Ethernet SFP28 x 2
Ports: 2 x 1Gb Ethernet/10Gb Ethernet/25Gb Ethernet - SFP28
Power and Environment
Power Draw (operating): 9.10 Watt
Compatible Systems
- HPE Nimble Storage dHCI Medium Solution with
- HPE ProLiant DL325 Gen10 Plus
- HPE ProLiant DL Series: DL110 Gen10 Plus Front Cabled Telco, DL20 Gen10 Plus, DL20 Gen10 Plus Base, DL20 Gen10 Plus Entry, DL20 Gen10 Plus High Performance, DL20 Gen10 Plus Performance, DL325 Gen10 Plus, DL325 Gen10 Plus All-NVMe Flash Node for Qumulo, DL325 Gen10 Plus All-NVMe Flash Node for Software Defined Storage, DL325 Gen10 Plus for Weka BAse Tracking, DL325 Gen10 Plus for Weka Expansion Tracking, DL325 Gen10 Plus V2, DL325 Gen10 Plus V2 Base, DL325 Gen10 Plus V2 for Weka Base Tracking, DL325 Gen10 Plus V2 Performance, DL345 Gen10 Plus Base, DL360 Gen10 Plus, DL360 Gen10 Plus All-NVMe Server for Software Defined Storage, DL365 Gen10 Plus, DL380 Gen10 Plus, DL380 Gen10 Plus Network Choice, DL385 Gen10 Plus, DL385 Gen10 Plus Entry
- HPE ProLiant ML Series: ML30 Gen10 Plus, ML30 Gen10 Plus Entry, ML30 Gen10 Plus Performance
- HPE ProLiant XL Series: XL220n Gen10 Plus, XL225n Gen10 Plus 1U Node, XL290n Gen10 Plus
Not sure this adapter fits your system? Send us your server or storage model and the DatorPro team will confirm compatibility before you order.
